Axiom AA1404033-E6-AX 40Gbase-Cr4 Qsfp+ to 4 10Gbase-Cu Sfp+ Passive Dac Avaya Compatible 1M View larger

Axiom AA1404033-E6-AX 40Gbase-Cr4 Qsfp+ to 4 10Gbase-Cu Sfp+ Passive Dac Avaya Compatible 1M

New

Axiom AA1404033-E6-AX 40GBASE-CR4 QSFP+ to 4×10GBASE-CU SFP+ passive DAC, Avaya compatible 1M.
×




  • New

Detailed Specifications

Accortec AA1403015-E6-ACC

10Gbps 10GBase-SR Multi-Mode Fiber 300m 850nm Duplex LC Connector SFP+ Transceiver

High-speed 10GbE SR multimode fiber transceiver.

Overview :

The Accortec AA1403015-E6-ACC is a 10Gbps SFP+ optical transceiver that supports the 10GBase-SR standard over multimode fiber. Operating at a wavelength of 850nm, it provides reliable connectivity up to 300 meters on OM3 fiber and up to 400 meters on OM4 fiber. Designed with a hot-swappable SFP+ form factor and duplex LC connector, this module ensures simple deployment and strong compatibility with enterprise switches and servers. Fully compliant with MSA specifications, the Accortec AA1403015-E6-ACC is ideal for data centers and enterprise LAN environments.

Features :

This Accortec transceiver is optimized for short-range 10GbE applications. It supports Digital Diagnostics Monitoring (DDM) for real-time optical performance monitoring, ensuring reliable network management. Its hot-swappable design minimizes downtime for replacements or upgrades, while low power consumption (<1w typical="" improves="" energy="" efficiency="" in="" dense="" deployments="" backed="" by="" enterprise-quality="" testing="" the="" a="" href="https://www.dcsupplies.net/445-accortec" data-mce-href="https://www.dcsupplies.net/445-accortec">Accortec module ensures stable link performance and 100% OEM compatibility.

Product Key Features

  • 10Gbps 10GBase-SR multimode fiber SFP+ by Accortec
  • Operates at 850nm for up to 300m (OM3)
  • LC Duplex connector, hot-swappable, MSA-compliant
  • Supports Digital Diagnostics Monitoring (DDM)

Reliability & Performance :

The Accortec AA1403015-E6-ACC delivers robust and consistent optical performance for short-reach 10GbE transmission. It reduces network latency through high-quality multimode fiber connectivity while offering energy efficiency with low power consumption. With hot-swappable flexibility, DDM support, and OEM validation, it ensures easy maintenance, proactive monitoring, and proven reliability within mission-critical infrastructures such as enterprise LAN, SAN, and campus networks.

Key Features :

  • 10GBASE-SR standard transceiver module
  • Supports 300m over OM3 MMF & 400m over OM4
  • Plug-and-play hot-swappable form factor
  • Backed by Accortec enterprise QA

Specifications :

SpecificationDetails
Model Number AA1403015-E6-ACC
Brand Accortec
Product Type 10G SFP+ Optical Transceiver
Standard 10GBASE-SR
Data Rate 10.3 Gbps
Wavelength 850nm
Fiber Type Multimode Fiber (OM3/OM4)
Max Distance 300m (OM3), 400m (OM4)
Connector LC Duplex
Form Factor Hot-Pluggable SFP+
Compatibility OEM & Avaya/Nortel equivalent systems
Power Consumption <1w typical="" td="">
DDM Support Yes (Digital Diagnostics Monitoring)
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to 85°C
Applications Data Centers, LANs, SANs
Diagnostics Optical Power, Voltage, Temperature
MSA Compliance Yes
TAA Compliance Yes
Certifications CE, FCC, RoHS
Warranty 3-Year by Accortec
