Detailed Specifications
OptiPlex 7020 Micro DesktopIntel Core i9-14900, 64 GB DDR5, 1 TB PCIe NVMe SSD, Windows 11 Pro
The DellOptiPlex 7020 Micro (Part #625D9) is engineered to deliver top-tier performance in a small form factor. Powered by the Intel Core i9-14900 processor (24 cores: 8P+16E, up to 5.5 GHz Turbo), it is ideal for demanding office applications, virtualization tasks, and multitasking-intensive environments. Preloaded with Windows 11 Pro, it supports seamless enterprise integration with enhanced security and manageability.
Features
The DellOptiPlex 7020 Micro Form Factor (MFF) delivers robust performance with the latest Intel vPro platform and next-gen DDR5 memory support.
Advanced Options
Designed for modern workplaces, it offers expanded manageability, dual M.2 SSD slots, multiple USB-C/DisplayPort outputs, and supports up to quad 4K displays via optional add-ons. The chassis supports flexible mounting (behind monitor, wall, under desk), making it ideal for minimal-footprint deployment without sacrificing power or connectivity.
Product Key Features
Intel Core i9-14900 (24-core hybrid, up to 5.5 GHz Turbo, 36 MB cache)
64 GB DDR5 RAM (2×32 GB DIMMs, dual-channel)
1 TB PCIe Gen 4 NVMe SSD (M.2 2280, fast boot and read/write)
Intel UHD 770 Graphics (supports 4K displays)
Windows 11 Pro preinstalled for secure business environments
Reliability & Performance
With enterprise-grade stability and Intel vPro platform, the OptiPlex 7020 ensures long-term performance and remote manageability. Its ultra-efficient thermal design allows sustained peak performance while remaining whisper-quiet. It's built to meet MIL-STD durability standards, supporting 24/7 operation with high power efficiency and long lifecycle components.
Key Features (Bullet List)
Intel Core i9-14900 (24 cores, 5.5 GHz Turbo)
64 GB DDR5 (2×32 GB) Dual-Channel Memory
1 TB PCIe Gen 4 NVMe SSD
Windows 11 Pro (64-bit, English)
Ultra-Compact Micro Form Factor Chassis
Intel UHD Graphics 770
Supports up to 4 monitors (with add-ons)
TPM 2.0, Secure Boot, and DellSafeBIOS
Wi-Fi 6E + Bluetooth 5.3 (optional)
Multiple USB 3.2 / USB-C / DisplayPort ports
Specifications :
Product Specifications
| Specification | Details |
|---|
| Model Number | Dell625D9 (OptiPlex 7020 MFF) |
| Processor | Intel Core i9-14900 (24 cores: 8P+16E, 32 threads, up to 5.5 GHz) |
| Chipset | Intel Q770 |
| Memory | 64 GB DDR5 (2×32 GB DIMMs, up to 96 GB supported) |
| Storage | 1 TB PCIe Gen 4 NVMe SSD (M.2 2280) |
| Graphics | Intel UHD Graphics 770 (Integrated) |
| Operating System | Windows 11 Pro (English, 64-bit) |
| Expansion | 2× M.2 (1 SSD, 1 Wi-Fi), 1× Flex I/O (HDMI/DP/USB-C option) |
| Networking | Intel Ethernet (1 GbE), optional Wi-Fi 6E and Bluetooth 5.3 |
| Ports | USB-C, USB 3.2 Gen 1/2, HDMI, DP, Audio, RJ-45, optional serial |
| Security Features | TPM 2.0, Dell SafeBIOS, chassis intrusion sensor |
| Power Supply | 130 W external adapter (Smart AC) |
| Form Factor | Micro Form Factor (MFF) |
| Dimensions (W×D×H) | 7.0″ × 7.2″ × 1.4″ (178 × 182 × 36 mm) |
| Weight | ~2.6 lbs (1.18 kg) |
