Detailed Specifications
APC SYBT3 - 808VAh Battery Module for Symmetra RM 8-12kVA
Overview
The APC SYBT3 is a lead-acid battery module designed for use with APC Symmetra RM 8-12kVA UPS systems. It provides an 808VAh capacity, ensuring extended runtime during power outages. The module features a 3-5 year battery life and is designed for internal placement within the UPS. With a net weight of 62.13 lb (28.18 kg), it is suitable for environments requiring reliable power backup solutions.
Key Features
808VAh capacity for extended runtime during power outages
3-5 year battery life for long-term reliability
Lead-acid battery type for stable performance
Internal battery placement for seamless integration
62.13 lb (28.18 kg) weight for manageable handling
Technical Specifications
| Specification | Detail |
|---|
| Brand | APC (Schneider Electric) |
| Part Number | SYBT3 |
| Product Type | Battery Module |
| Key Spec 1 | Battery Capacity: 808VAh |
| Key Spec 2 | Battery Type: Lead-Acid |
| Key Spec 3 | Battery Life: 3-5 years |
| Management | Passive - no active electronics |
| Power Requirements | Input: 100-120V AC, 50/60 Hz; Output: 120V AC |
| Dimensions & Weight | Dimensions: 6.5" x 5.31" x 23.11"; Weight: 62.13 lb (28.18 kg) |
| Warranty | 2-year limited warranty |
