Detailed Specifications
Industrial Barcode Label Printer - PM65 Series
The Honeywell PM65A11000030201 is a heavy-duty industrial barcode label printer built for high-volume output and precision in harsh environments. Designed for manufacturing and logistics sectors, it features WWAN connectivity, remote diagnostics, and versatile media handling for enterprise-grade performance.
Features :
Ideal for demanding sectors such as pharmaceuticals, manufacturing, and warehousing, this high-performance printer delivers consistent, sharp labels at speeds up to 14 inches per second. The PM65A supports remote configuration, diagnostics, and management with Honeywell Printer Edge' and Print Set MC, offering real-time control from Android and iOS devices. WWAN capability ensures always-on connectivity across distributed operations.
Advanced Options :
Built with a rugged all-metal frame, the PM65A is engineered for 24/7 operation in high-demand environments. Tool-free maintenance, including easy media and printhead replacement, minimizes downtime. The printer supports a wide range of media types and advanced interfaces like RFID, industrial, and parallel for future scalability. Accurate print registration up to ±0.5 mm ensures compliance-ready output even on small or detailed labels.
Product Key Features
- High-precision printing with ±0.5 mm registration accuracy
- WWAN connectivity for remote diagnostics and monitoring
- RFID, parallel, and industrial interface support for future-proof scalability
- Durable all-metal construction built for industrial environments
- Tool-free printhead and media replacement for minimized downtime
- Mobile configuration via Android' and iOS devices
Reliability & Performance :
The Honeywell PM65A11000030201 is built to handle high-throughput demands with outstanding reliability. With a durable frame, intelligent heat control, and hot-swappable components, it keeps production lines moving with minimal intervention. High-resolution printing and support for multiple media formats ensure clarity, compliance, and long-term performance across industrial applications.
Key Features :
- High-resolution 600 dpi output for ultra-clear labels
- Fast print speed up to 14 inches per second
- Advanced WWAN connectivity for remote visibility
- Flexible interface support including RFID and parallel ports
- All-metal design with tool-free component access
Specifications :
| Specification | Details |
|---|
| Model Number | PM65A11000030201 |
| Printer Type | Barcode Label Printer |
| Max Print Width | 4.09 inches (104 mm) |
| Max Print Speed | Up to 14 inches/sec |
| Resolution | 600 dpi |
| Interface Options | WWAN, RFID, parallel, industrial, USB, Ethernet |
| Media Types | Labels, tags, ribbons (ink-in/out compatible) |
| Media Width | 1 inch to 4.65 inches (25.4 mm to 118 mm) |
| Power Supply | External AC adapter |
| Dimensions (WxDxH) | 10 x 16 x 8 inches (254 x 406 x 203 mm) |
| Weight | Approx. 25 lbs (11.3 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Connectivity | WWAN, Ethernet, USB, optional RFID interface |
