Accortec 100G-AOC-3M-ACC 100GBase QSFP Active Optical Cable 3-meter View larger
Previous Next

Accortec 100G-AOC-3M-ACC 100GBase QSFP Active Optical Cable 3-meter

New

Accortec 100G-AOC-3M-ACC 100GBase QSFP

×




  • New

Detailed Specifications

Accortec

100G‑AOC‑3M‑ACC – 100 GBase QSFP28 Active Optical Cable | 3 Meter (9.84 ft)

The Accortec 100G‑AOC‑3M‑ACC is a high-performance 100 Gbps QSFP28 Active Optical Cable (AOC), expertly designed for data centers and enterprise networking environments. At 3 meters (9.84 ft) in length, it supports full-duplex transmission over OM3/OM4 multimode fiber, delivering reliable 100 GBase-Ethernet or InfiniBand speeds. Factory-programmed for multi-vendor compatibility—including Cisco, Arista, Juniper, Mellanox, and more—it provides plug-and-play simplicity, low power consumption, and real-time diagnostics (DDM), making it ideal for high-density rack-to-rack or switch-to-switch interconnects.

Features

This AOC integrates optical transceivers directly into the QSFP28 connectors—eliminating the need for separate optics modules and reducing system heat and cabling clutter. By using 850 nm VCSEL optics, it transmits 4×25 Gbps lanes (aggregate 100 Gbps) across a 3-meter multimode fiber run with ultra-low latency and EMI resistance.

Advanced Options

 Accortec encodes EEPROM metadata to match OEM firmware expectations, ensuring seamless interoperability in heterogeneous networking setups. The thin, flexible LSZH cable enhances airflow and simplifies cable management.

Product Key Features

  • QSFP28-to-QSFP28 100 G Active Optical Cable

  • 3 Meter length (approx. 9.84 ft) over OM3/OM4 fiber

  • Supports 100 GbE (IEEE 802.3bm), InfiniBand EDR, OTU4

  • Factory-programmed compatibility with Cisco, Juniper, Arista, Mellanox, etc.

  • Low power use (~2.5–3.5 W per end typical)

  • MSA, IEEE 802.3bm, SFF‑8665, RoHS, and TAA compliant

  • LSZH fiber jacket, flexible and bend-resistant

  • Hot‑swappable plug-and-play installation

  • Digital Diagnostics Monitoring (DDM) supported

  • Lifetime warranty & 30‑day return policy

Reliability & Performance

The 100G‑AOC‑3M‑ACC has been pre-qualified through electrical and optical validation procedures—including BER testing and eye-diagram stability—ensuring reliable performance in mission-critical deployments. Its active optical design curbs EMI and supports more consistent throughput than copper DACs over similar distances. The integrated diagnostics provide real-time insights into link health, such as optical power, temperature, and voltage. Coupled with its thin LSZH profile, it's built for high-density rack deployments while maintaining thermal and cable routing efficiency.

Key Features (Bullet List)

  • QSFP28-to‑QSFP28 100 G Active Optical Cable

  • 3 Meter (9.84 ft) multimode fiber link

  • Full-speed 100 GbE (4×25 Gbps lanes)

  • Vendor-programmed plug-and-play I²C EEPROM

  • Low power draw (~2.5–3.5 W per connector)

  • Supports DDM diagnostics (platform-dependent)

  • Compliance with IEEE 802.3bm, MSA, TAA, RoHS, SFF‑8665

  • Compact LSZH jacket with small bend radius

  • Hot-swappable in-field installable design

  • Lifetime limited warranty and 30‑day return policy

Specifications :

Product Specifications
SpecificationDescription
Part Number 100G‑AOC‑3M‑ACC
Cable Type Active Optical Cable (QSFP28 form factor)
Connector Type QSFP28 to QSFP28
Cable Length 3 meters (~9.84 ft)
Wavelength / Optics 850 nm VCSEL over OM3/OM4 fiber
Data Rate 100 Gbps (IEEE 802.3bm)
Power Consumption ~2.5–3.5 W per end
Operating Temp Range 0 °C to 70 °C
Compliance MSA, IEEE 802.3bm, SFF‑8665, RoHS, TAA
Diagnostics Digital Diagnostics Monitoring (DDM)
Cable Jacket LSZH, flexible with ~30 mm minimum bend radius
Altitude/EMI Tolerance High immunity due to optical medium
Installation Hot‑swappable, plug‑and‑play
Warranty / Returns Lifetime warranty, 30‑day return policy
