Detailed Specifications
4U Wall-Mount Server Rack with Dual Fans & Lock
The StarTech RK419WALVS is a 4U wall-mountable server rack designed for secure installation of servers, switches, patch panels, or non-rack gear in space-constrained environments. With locking doors and heavy-gauge steel panels, it provides enterprise-grade protection and access control×ideal for branch offices, retail, telecom, and industrial settings.
Features
This compact 19-inch rack includes two 120 mm cooling fans delivering up to 106 CFM of airflow to protect hardware from overheating. It supports both horizontal rackmounting and vertical wall-case installations×adding flexibility for non-rack mountequipment via the included steel shelf. Mounting holes align to standard studs for easy, reliable wall attachment.
Advanced Options
Engineered to EIA-RS-310D standards and RoHS/REACH/UL/CE certified, this TAA-compliant rack offers 19″ compatibility and a weight capacity of 150 lb (68 kg). The hinged lockable front panel, latch-secured side, and lifetime warranty ensure durability and secure operations in professional IT environments.
Product Key Features
Secure wall-mount enclosure with keyed locks on door and main body
Dual 120 mm built-in fans for active cooling
Compact 4U rack with optional steel plate shelf for non-rackmount gear
Mounting holes spaced at 16″ for easy stud installation
EIA-310/RS-310 compliant 19″ rack depth (28.4″), holds up to 150 lb (68 kg)
TAA compliant with rugged solid-steel construction
Reliability & Performance
Rated with an MTBF of 1.6 million hours, this drive is built for constant uptime in high-demand server environments. It supports hot-plug functionality, allowing IT teams to replace or scale storage without downtime. Its enterprise-class shock and vibration resistance enhances longevity, while efficient power usage keeps operational costs low in energy-conscious data centers.
Key Features :
4U secure wall-mount rack with keyed locks
Dual 120 mm fans (92-106 CFM, 42-46 dBA)
Supports 150 lb (68 kg) load capacity
EIA-310/RS-310 standard 19″ width
16″ stud-spacing mounting for fast installation
Includes optional steel shelf for non-rack gear
| Specification | Details |
|---|
| Model Number | RK419WALVS |
| Product Type | 4U Wall-Mount Server Rack Cabinet |
| Rack Units | 4U |
| Rack Width | 19″ (EIA-310/RS-310 compliant) |
| External Dimensions (HxWxD) | 8.6″ × 25.4″ × 28.5″ (219 × 644 × 725 mm) |
| Internal Dimensions (HxWxD) | 7″ × 19″ × 28.4″ (178 × 485 × 721 mm) |
| Material | Solid Steel (SPCC) |
| Color | Black |
| Cooling | 2 × 120 mm fans; 92-106 CFM; 42-46 dBA |
| Load Capacity | 150.3 lb (68 kg) |
| Mounting | Wall-mount with 16″ stud alignment |
| Locking Mechanism | Hinged front door + side latch |
| Included Accessories | Keys, screws, cage nuts, optional steel shelf |
| Certifications | UL, CE, RoHS, REACH, TAA compliant |
