Ergotron 33-350-200 – WorkFit-S Single LD Workstation with Worksurface
Overview
The Ergotron 33-350-200 is a WorkFit-S Single LD sit-stand workstation with an integrated worksurface and large keyboard tray. The black workstation attaches to an existing desk or work surface using a desk clamp and provides height-adjustable positioning for a single LCD monitor and keyboard.
Technical Information
The WorkFit-S uses counterbalanced adjustment to allow the monitor and keyboard to be repositioned without tools. The LCD and keyboard can be adjusted together through a 18-inch (46 cm) range, while the LCD provides an additional 4.8-inch (12.2 cm) independent adjustment. The maximum LCD height adjustment is 22.8 inches (58 cm).
The workstation supports an LCD weighing 6–16 lb (2.7–7.3 kg), with a maximum total load of 18 lb (8.2 kg) on the height-adjustment assembly. The total load includes the LCD, worksurface, and keyboard tray. The LCD mount supports VESA MIS-D mounting patterns and provides up to 30° of tilt and 360° of rotation.
Compatibility
The 33-350-200 is designed for single LCD monitor applications using displays within the supported weight range. Ergotron documentation identifies the model as the Single LD configuration with Worksurface. The desk clamp attaches to a desk or worksurface edge measuring 1.2–6 cm (0.47–2.4 inches) thick.
The workstation can also be configured for notebook use by adding the compatible Ergotron LX Notebook Tray, part number 50-193-200. When used as a computer workstation, Ergotron recommends a separate external keyboard for proper ergonomic positioning.
Key Features
- Single-monitor WorkFit-S sit-stand workstation with integrated worksurface
- 18-inch (46 cm) tandem adjustment for LCD and keyboard
- Additional 4.8-inch (12.2 cm) independent LCD adjustment
- Supports LCDs weighing 6–16 lb (2.7–7.3 kg) with 18 lb (8.2 kg) maximum total assembly load
- Includes height-adjustment column, desk clamp, LCD pivot, worksurface, and large keyboard tray
Applications
The 33-350-200 is suited to office, workstation, IT deployment, and other environments where an existing desk needs to be converted into a sit-stand computer workstation. Its integrated worksurface and keyboard tray provide a dedicated platform for a single monitor, keyboard, and mouse while allowing the user to alternate between seated and standing positions.
DC Supplies Product Note
Verify the LCD weight, combined component load, VESA interface, and desk thickness before installation. The maximum total load of the height-adjustment assembly is 18 lb (8.2 kg), including the LCD, worksurface, and keyboard tray. The desk clamp requires a compatible surface edge between 1.2 and 6 cm thick.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number / MPN | 33-350-200 |
| Product Type | Sit-Stand Workstation |
| Product Series | WorkFit-S |
| Configuration | Single Monitor LD with Worksurface |
| Color | Black |
| Recommended Display Size | Up to 27 in |
| LCD Weight Range | 6–16 lb (2.7–7.3 kg) |
| Maximum Total Load | 18 lb (8.2 kg) |
| LCD and Keyboard Lift | 18 in (46 cm) tandem adjustment |
| Independent LCD Adjustment | 4.8 in (12.2 cm) |
| Maximum LCD Height Adjustment | 22.8 in (58 cm) |
| Tilt | 30° |
| Rotation | 360° |
| VESA Mounting | MIS-D; 75 x 75 mm and 100 x 100 mm |
| Desk Clamp Thickness | 1.2–6 cm (0.47–2.4 in) |
| Worksurface Dimensions | 58.5 x 38 cm |
| Keyboard Tray Dimensions | 68.5 x 22.6 cm |
| Included Components | Height-adjustment column, desk clamp, LCD pivot, worksurface, large keyboard tray |
| Notebook Configuration | Compatible with LX Notebook Tray 50-193-200 |
| Warranty | 5 years |
FAQs
What is the Ergotron 33-350-200?
The Ergotron 33-350-200 is a WorkFit-S Single LD sit-stand workstation with a worksurface and large keyboard tray for a single LCD monitor.
What monitors are supported?
The 33-350-200 is designed for single LCD displays in the LD configuration. Ergotron documentation specifies an LCD weight range of 6–16 lb (2.7–7.3 kg), with typical display size up to 27 inches.
What is the maximum total load?
The maximum total load on the height-adjustment assembly is 18 lb (8.2 kg). This total includes the LCD, worksurface, and keyboard tray.
How much height adjustment is available?
The LCD and keyboard adjust together through 18 inches (46 cm). The LCD also provides 4.8 inches (12.2 cm) of independent adjustment, giving a maximum LCD height adjustment of 22.8 inches (58 cm).
What VESA mounting patterns are supported?
The LCD mount uses the VESA MIS-D interface and supports 75 x 75 mm and 100 x 100 mm mounting patterns.
How does the workstation attach to a desk?
The WorkFit-S attaches using a desk clamp designed for surfaces with an edge thickness of 1.2–6 cm (0.47–2.4 inches).
Can the 33-350-200 be used with a notebook?
Yes. Ergotron identifies the LX Notebook Tray, part number 50-193-200, as an accessory that can be used to configure the workstation for notebook applications.
What is included with the 33-350-200?
The workstation includes the height-adjustment column, desk clamp, LCD pivot, worksurface, and large keyboard tray.
What is the warranty?
Ergotron documentation specifies a 5-year warranty for the WorkFit-S configuration.
