Detailed Specifications

HPE JX955A Aruba Instant IAP-207 (US) - wireless access point

Overview :

The affordable, mid-range Aruba 207 Series Access Points deliver high performance 802.11ac for medium density enterprise environments, such as schools, retail branches, warehouses, hotels and enterprise offices, where the environment is cost sensitive. JX955A The compact Aruba 207 Series AP delivers a maximum concurrent data rate of 867Mbps in the 5GHz band and 400 Mbps in the 2.4GHz band (for an aggregate peak data rate of 1.3Gbps). With the integrated Bluetooth Aruba Beacon, the 207 Series AP provides advanced location and indoor way finding, and proximity-based push notification services while simplifying the remote management of battery-powered Aruba Beacons.

Specifications :

Main Features

  • Wireless access point
  • Wi-Fi
  • Dual Band
  • in-ceiling
  • Networking

  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az
  • Wireless
  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • 2T2R MIMO technology, Adaptive Radio Management (ARM), Advanced Cellular Coexistence (ACC), Auto-uplink (auto MDI/MDI-X), Ceiling mountable, ClientMatch, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, Energy Efficient Ethernet, Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), Reset button, Security lock slot (cable lock sold separately), Space Time Blocking Code (STBC), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Wall mountable
  • In-ceiling
  • PoE
  • Link/activity, Power, Status
  • Wireless access point
  • 2.4 GHz, 5 GHz
  • 802.11a/b/g/n/ac
  • Interface Provided

  • RJ-45
  • 1
  • 1000Base-T
  • Console
  • Miscellaneous

  • CB, cTUVus, EN 300 328, EN 301 489, EN 301 893, EN 60601-1-1, EN 60601-1-2, EN 60950, FCC, FIPS, IEC 60950, LVD 72/23/EEC, R&TTE Directive 1995/5/EC, UL 2043, UL 60950
  • Mounting brackets
  • 753457 hours
  • Antenna

  • Internal
  • 4
  • Omni-directional JX955A
  • Service

  • Lifetime
  • Limited warranty
  • Environmental Parameters

  • 5 - 93% (non-condensing)
  • 122 °F
  • 32 °F
  • Header

  • Aruba
  • PC
  • Aruba
  • IAP-207 (US)
  • 1
  • Aruba Instant
  • Line Properties

  • 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, QPSK
  • Dimensions & Weight

  • 5.9 in
  • 1.6 in
  • 13.4 oz
  • 5.9 in
  • Service & Support

  • Limited lifetime warranty
  • Chassis

  • Indoor
  • Optical Storage

  • None
