Detailed Specifications
Netgear WAX214PA-100NAS AX1800 Dual-Band PoE Access Point
Overview :
The Netgear WAX214PA-100NAS is a WiFi 6 (802.11ax) access point designed for small businesses, retail stores, and branch offices. It provides up to 1.8 Gbps total wireless throughput with dual-band 2.4 GHz and 5 GHz radios. The unit is ideal for ceiling or wall mounting to ensure strong, even coverage. It supports both PoE and DC power for flexible installation options.
Key Features :
AX1800 dual-band WiFi 6 connectivity
1 GbE port supporting PoE (802.3af/at)
WPA3 and WPA2 security support
Wall or ceiling mount hardware included
Technical Specifications :
| Specification | Value |
|---|
| Brand | Netgear |
| Part Number | WAX214PA-100NAS |
| Product Type | Dual-Band WiFi 6 PoE Access Point |
| Wireless Standard | IEEE 802.11ax / ac / n / a / b / g |
| Maximum Throughput | 1,800 Mbps (600 Mbps @ 2.4 GHz + 1,200 Mbps @ 5 GHz) |
| Ethernet Interface | 1 × 10/100/1000 Mbps RJ-45 (PoE) |
| Power Options | PoE (802.3af/at) or 12 V DC / 1.5 A adapter (included) |
| Antenna Gain (Peak) | 2.4 GHz: 3 dBi / 5 GHz: 4 dBi |
| Max Clients | Up to 128 clients |
| SSIDs Supported | Up to 4 SSIDs |
| Mounting Options | Wall or ceiling mount |
| Dimensions (W × D × H) | 160.9 × 160.9 × 33.28 mm |
| Weight | 0.38 kg |
| Operating Temperature | 0 °C to 40 °C |
