Overview
The Ubiquiti U7 Pro XG is a six-stream tri-band WiFi 7 access point for high-performance UniFi wireless deployments. It provides 2.4 GHz, 5 GHz, and 6 GHz connectivity, a 10 GbE Ethernet uplink, and PoE+ power. Ubiquiti specifies coverage of up to 140 m² (1,500 ft²) and support for more than 300 clients.
Wireless Connectivity
The U7 Pro XG uses 2x2 MU-MIMO on each of its three wireless bands. Maximum specified data rates are 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz, and 5.8 Gbps on 6 GHz. WiFi 7 operation supports EHT channel widths up to 320 MHz on the 6 GHz band.
Network and Management Features
The access point provides a single 10 GbE RJ45 port and supports UniFi wireless management features including wireless meshing, band steering, fast roaming, radio resource management, Passpoint, guest network isolation, PPSK, WiFi speed limiting, client isolation, WiFi scheduling, RADIUS over TLS, and dynamic RADIUS-assigned VLANs.
Deployment
The U7 Pro XG supports ceiling or wall mounting and includes a Lite Mount. Its compact circular enclosure measures 206 mm in diameter and 32.5 mm in height. The access point is powered through PoE+ and has a maximum power consumption of 22 W.
Key Features
- Tri-band WiFi 7 with 2.4 GHz, 5 GHz, and 6 GHz radios
- Six spatial streams using 2x2 MU-MIMO on each band
- 10 GbE RJ45 uplink
- Up to 5.8 Gbps specified maximum 6 GHz data rate with 320 MHz bandwidth
- Ceiling or wall mounting with Lite Mount included
Applications
The U7 Pro XG is intended for UniFi wireless networks requiring WiFi 7 connectivity, 6 GHz operation, and a high-speed Ethernet uplink. Its multi-band radio configuration and UniFi management features support enterprise and other high-performance indoor wireless deployments.
DC Supplies Product Note
The U7 Pro XG requires a PoE+ power source and provides a 10 GbE RJ45 uplink. Network infrastructure should therefore support the required Ethernet speed and PoE+ power requirements. Ubiquiti specifies UniFi Network version 9.0.114 or later for the white U7 Pro XG and version 9.1.120 or later for the black version.
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | U7-Pro-XG |
| Product Type | WiFi 7 Access Point |
| Model | U7 Pro XG |
| WiFi Standard | WiFi 7 |
| Spatial Streams | 6 |
| Wireless Bands | 2.4 GHz / 5 GHz / 6 GHz |
| Coverage Area | 140 m² (1,500 ft²) |
| Maximum Client Count | 300+ |
| Uplink | 10 GbE |
| Networking Interface | 1 x 10 GbE RJ45 |
| Mounting | Ceiling, Wall |
| Power Method | PoE+ |
| Maximum Power Consumption | 22 W |
| Supported Voltage Range | 42.5–57 V DC |
| 2.4 GHz MIMO | 2 x 2 DL/UL MU-MIMO |
| 5 GHz MIMO | 2 x 2 DL/UL MU-MIMO |
| 6 GHz MIMO | 2 x 2 DL/UL MU-MIMO |
| Maximum 2.4 GHz Data Rate | 688 Mbps |
| Maximum 5 GHz Data Rate | 4.3 Gbps |
| Maximum 6 GHz Data Rate | 5.8 Gbps |
| Antenna Gain | 4 dBi (2.4 GHz), 5 dBi (5 GHz), 6 dBi (6 GHz) |
| Maximum TX Power | 23 dBm (2.4 GHz), 26 dBm (5 GHz), 24 dBm (6 GHz) |
| Dimensions | Ø206 x 32.5 mm (Ø8.1 x 1.3 in) |
| Weight | 750 g (1.7 lb) |
| Operating Temperature | -30 to 40 °C (-22 to 104 °F) |
| Operating Humidity | 5–95% noncondensing |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mount Material | Stainless steel (SUS304), galvanized steel (SGCC) |
| Certifications | CE, FCC, IC, Anatel: 06630-25-08356 |
| NDAA Compliant | Yes |
| UniFi Network Requirement | Version 9.0.114+ (White); Version 9.1.120+ (Black) |
FAQs
What WiFi standard does the U7 Pro XG support?
The U7 Pro XG supports WiFi 7 (802.11be), as well as WiFi 6, WiFi 5, and WiFi 4 operation.
Does the U7 Pro XG support the 6 GHz band?
Yes. The access point includes a dedicated 6 GHz radio with 2x2 MU-MIMO and a specified maximum data rate of 5.8 Gbps using 320 MHz bandwidth.
What Ethernet connection does the U7 Pro XG have?
It has one 10 GbE RJ45 networking port for the Ethernet uplink.
How is the U7 Pro XG powered?
Ubiquiti specifies PoE+ power, with a supported voltage range of 42.5–57 V DC and maximum power consumption of 22 W.
Can the U7 Pro XG be wall mounted?
Yes. Ubiquiti specifies both ceiling and wall mounting, with the Lite Mount included.
