Detailed Specifications
Teltonika DAP142000000 Wi-Fi 6 Access Point
Overview
The Teltonika DAP142000000 is a dual-band Wi-Fi 6 access point built for network engineers deploying high-capacity wireless LAN in enterprises, campuses, hospitality, and dense environments. It delivers 802.11ax performance on both 2.4 GHz and 5 GHz bands with OFDMA and MU-MIMO for concurrent multi-device traffic. The device integrates flexible mounting options and supports centralized management, enabling scalable wireless coverage with roaming and security features. It fits indoor deployments where upgraded throughput and device density handling are required.
Key Features
• Dual-band 802.11ax (Wi-Fi 6) radio
• OFDMA and MU-MIMO support
• Up to four spatial streams
• PoE or DC power input
Technical Specifications
| Specification | Details |
|---|
| Brand | Teltonika |
| Part Number | DAP142000000 |
| Product Type | Dual-Band Wi-Fi 6 Access Point |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6) |
| Frequency Bands | 2.4 GHz & 5 GHz |
| Max Data Rate | Up to 1200 Mbps (2.4 GHz) + 2400 Mbps (5 GHz) |
| Spatial Streams | Up to 4×4 |
| Antennas | Internal high-gain |
| PoE | 802.3af/at support |
| Power Input | PoE or 12 V DC |
| Ethernet | 1× Gigabit RJ45 |
| Mounting | Ceiling/Wall mount brackets |
| Security | WPA3, WPA2 |
| Dimensions | 200 × 200 × 35 mm (7.87 × 7.87 × 1.38 in) |
| Weight | 550 g (1.21 lbs) |
| Operating Temp. | 0 °C to 40 °C |
