Detailed Specifications
HPE J9368A MSM320-R Outdoor 802.11a/b/g Access Point
Overview
The HPE J9368A (MSM320-R) is an outdoor-rated dual-radio wireless access point supporting the IEEE 802.11a/b/g standards on both 2.4 GHz and 5 GHz bands. Its rugged enclosure is built for deployment in external environments and supports 10/100 BASE-T uplink via PoE power. With dual radios and two external antenna connectors, it provides flexibility for directional or omni-coverage in campus, school or hospitality outdoor spaces. The unit is designed for mesh or infrastructure-mode deployments and integrates into centralized WLAN control systems, making it suitable for managed outdoor wireless coverage areas, wireless bridges or distributed campus networks. Built for harsh environment durability, the MSM320-R model supports wide ambient temperature ranges and outdoor mounting hardware, enabling reliable service in non-climate-controlled shelters, pole-mounts or rooftop installations.
Key Features
Dual-radio support across 2.4 GHz and 5 GHz bands (802.11a/b/g)
Outdoor-rated enclosure with mount kit for walls/poles
Single 10/100 BASE-T uplink port with PoE support
Two external antenna connectors for flexible coverage or mesh links
Technical Specifications
| Specification | Value |
|---|
| Brand | HPE |
| Part Number | J9368A |
| Product Type | Outdoor Dual-Radio 802.11a/b/g Access Point |
| Wireless Standards | IEEE 802.11a, 802.11b, 802.11g |
| Maximum Data Rate | Up to 54 Mb/s (on 802.11a/b/g) |
| Radio Configuration | Dual-radio |
| Uplink Interface | 1 × 10/100 BASE-T (RJ-45) |
| Antenna Connectors | 2 × external N-type (one per radio) |
| Power | IEEE 802.3af PoE compatible |
| Dimensions (D × W × H) | 8.44″ × 7.25″ × 2.14″ (≈ 21.44 cm × 18.42 cm × 5.44 cm) |
| Weight | ~9.0 lb (~4.08 kg) |
| Outdoor Rating | IP65/NEMA-4 (rugged housing) |
| Operating Temperature Range | -20 °C to 50 °C |
| Mounting Options | Wall or pole mount kit included |
| Use Case | Outdoor wireless coverage, campus mesh or bridge links |
