Detailed Specifications
HPE AP-504-US Indoor Dual-Radio 802.11ax Access Point
Overview
The HPE AP-504-US is an indoor wireless access point designed for medium-density environments such as offices, classrooms or retail venues where modern Wi-Fi 6 (802.11ax) connectivity and external antenna flexibility are needed. It supports dual-radio operation on the 2.4 GHz and 5 GHz bands in a 2×2:2 MIMO configuration, offering efficient support for multiple clients with enhanced spectral efficiency. With support for OFDMA, MU-MIMO (downlink) and advanced client-steering features, it helps deliver reliable connectivity while optimising airtime usage in concurrent multi-device scenarios. The unit includes external antenna connectors to accommodate customised coverage patterns, and supports Power over Ethernet (PoE) or DC power options for flexible deployment. Integrated security features such as WPA3 and Enhanced Open are included, and the AP is compatible with wired-wireless policy systems to align with enterprise network architecture.
Key Features
Dual-band Wi-Fi 6 (802.11ax) with 2×2:2 MIMO for high-efficiency access
External-antenna connectors for customised RF coverage
Maximum combined data rate up to approximately 1.49 Gb/s
Supports PoE or DC power input for flexible installation
Technical Specifications
| Specification | Value |
|---|
| Brand | HPE |
| Part Number | AP-504-US |
| Product Type | Indoor Dual-Radio Wi-Fi 6 Access Point |
| Wireless Standard | IEEE 802.11ax |
| MIMO Configuration | 2×2:2 |
| Maximum Combined Data Rate | Up to ~1.49 Gb/s |
| Uplink Interface | 1×10/100/1000 BASE-T RJ-45 |
| Power Options | PoE (802.3af/at) or 12 V DC |
| Mounting Options | Ceiling or wall mount |
| Dimensions (W × D × H) | ~6.3″ × ~6.34″ × ~1.46″ |
| Weight | ~1.10 lb (~0.50 kg) |
| Radio Features | OFDMA, MU-MIMO, target wake time (TWT) |
| Antenna Configuration | External dual-band connectors |
| Security Protocols | WPA3, Enhanced Open, 802.1X |
| IoT-Ready Features | Bluetooth 5, Zigbee support built-in |
| Client Density Suitability | Medium-density indoor deployments |
