Netgear WAX630E-100CNS Tri Band 7.80 Gbit/s Wireless Access Point View larger
Previous Next

Netgear WAX630E-100CNS Tri Band 7.80 Gbit/s Wireless Access Point

New

Netgear Tri Band 7.80 Gbit/s

×




  • New

Detailed Specifications

Netgear

WAX630E-100CNS Tri-Band WiFi 6E Wireless Access Point

The Netgear WAX630E-100CNS is a cutting-edge tri-band WiFi 6E Wireless Access Point purpose-built for small to medium-sized businesses craving blazing-fast connectivity and future-ready performance. With support across 2.4 GHz, 5 GHz, and the all-new 6 GHz band, it delivers up to 7.8 Gbps aggregated throughput—ideal for high-density environments like schools, hotels, and office complexes. It’s well suited for IT managers and business professionals who need seamless, reliable wireless coverage that can handle a surge of modern devices—from smartphones and IoT gadgets to high-bandwidth laptops and streaming systems. The result? A wireless experience that's fast, secure, and effortless to manage, helping businesses deliver exceptional performance and keep up with evolving network demands.

Features

The WAX630E harnesses the power of WiFi 6 Release 2 (WiFi 6E), adding the cleaner, broader 6 GHz spectrum to traditional bands to dramatically reduce interference and boost channel capacity. By supporting 160 MHz channel widths on both 5 GHz and 6 GHz bands, it doubles throughput over earlier WiFi 6 models and offers better performance under load

Advanced Options

Managed seamlessly through Netgear Insight—either via mobile app or cloud portal—the WAX630E simplifies deployment and ongoing oversight. It integrates effortlessly with existing Netgear Insight-managed switches, APs, and storage devices, enabling scalable, mesh-capable networks without demanding advanced IT expertise

Product Key Features

  • Tri-band WiFi 6E support (2.4 GHz, 5 GHz, 6 GHz) – AXE7800 up to 7.8 Gbps

  • 2.5 GbE PoE++ port plus 1 GbE port for redundancy/link aggregation

  • Enterprise-grade security (WPA3, WPA2 Enterprise, Dynamic VLANs, 8 SSIDs)

  • OFDMA, MU-MIMO, BSS Coloring, TWT, Beamforming+ for high efficiency

  • Insight cloud/mobile management with instant mesh/backhaul capability

Reliability & Performance

Built for durability and enterprise readiness, the Netgear WAX630E features robust internal antenna design and reliable wall or ceiling mounting options. It supports backward compatibility with earlier WiFi standards, ensuring smooth legacy device integration. With advanced energy-saving technologies like Target Wake Time (TWT) and efficient PoE++ support, it balances high output (up to ~30 W) with energy-conscious operation .

Key Features

  • Tri-band (2.4 GHz / 5 GHz / 6 GHz) WiFi 6E – AXE7800, up to 7.8 Gbps

  • 2.5 GbE PoE++ port and 1 GbE port for redundancy/link aggregation

  • Advanced security: WPA3, WPA2 Enterprise, 8 SSIDs, VLAN support

  • High-efficiency radio features: OFDMA, MU-MIMO, BSS Coloring, TWT, Beamforming+

  • Insight-managed with instant mesh/backhaul and cloud/mobile control

Specifications :

SpecificationDetail
Model Number WAX630E-100CNS
Type Tri-Band WiFi 6E Wireless Access Point (AXE7800)
Capacity (Max Throughput) 7.8 Gbps (600 Mbps @2.4 GHz, 4800 Mbps @5 GHz, 2400 Mbps @6 GHz)
Streams 8-stream (Tri-band)
Form Factor Wall/ceiling mountable (internal antennas)
Interface 1×2.5 GbE PoE++, 1×1 GbE
Power PoE++ (802.3bt), up to ~30 W; fallback 802.3at with reduced performance
Ports 2 (Ethernet, PoE)
Dimensions 266.6 × 268.3 × 55.5 mm (10.49×10.56×2.18 in)
Weight ~1050 g (~2.31 lb)
Security Features WPA3, WPA2 Enterprise, Dynamic VLAN, Captive Portal, 8 SSIDs
Management Netgear Insight (Cloud & App), 1-year subscription included
