NETGEAR WAX610PA-100CNS - Wireless access point View larger

NETGEAR WAX610PA-100CNS Insight Managed Dual-Band Wireless Access Point

New

AX1800 Dual-Band Insight WiFi 6 AP
×




  • New

Detailed Specifications

NETGEAR WAX610PA-100CNS Insight Managed Dual-Band Access Point

Overview

The NETGEAR WAX610PA-100CNS is a dual-band WiFi 6 access point managed via NETGEAR Insight, targeted at SMBs and enterprises needing reliable indoor wireless coverage. It supports 2×2 radios on both 2.4 GHz and 5 GHz bands, delivering aggregate throughput up to 1.8 Gbps. It includes a 2.5 Gbps Ethernet port with support for 802.3at PoE (or optional DC power) for flexible deployment. It fits well in offices, hospitality, education, or any environment requiring centralized dashboard control and seamless scaling.

Key Features

  • Dual-band 802.11ax (WiFi 6) with 1.8 Gbps aggregate

  • 2.5 Gbps Ethernet port with PoE+ support

  • Insight cloud/web management via NETGEAR Insight

  • Mesh and multi-AP backhaul support

SpecificationDetails
Brand NETGEAR
Part Number WAX610PA-100CNS
Product Type Insight Managed Dual-Band Access Point
WiFi Standard IEEE 802.11ax (WiFi 6)
Radios / Streams 2×2 on 2.4 GHz + 2×2 on 5 GHz (4 streams)
Max Aggregate Throughput 1.8 Gbps (300 Mbps @2.4 GHz + 1,200 Mbps @5 GHz)
Ethernet Port 1 × 10/100/1000/2.5GBASE-T RJ-45 with Auto Uplink
PoE Support IEEE 802.3at (PoE+) ≈ 15.3 W
Alternate Power 12 V DC, 2.5 A adapter
Client Capacity Up to 250 users / 50 concurrent clients
Mesh / Backhaul Instant WiFi mesh with other WAX610 / WAC540 / WAX610Y units
Security Features WPA3, WPA2, WPA Enterprise, 8 SSIDs, VLANs
Management NETGEAR Insight cloud / web portal
Dimensions (W × D × H) 160.9 × 160.9 × 33.25 mm
Weight 412 g
Operating Temperature 0 °C to 40 °C
