Netgear EAX20-100NAS 4-Stream AX1800 Dual-Band Wireless Mesh Extender

New

Netgear EAX20 802.11ax 1.76 Gbit/s Wireless Range Extender - 2.40 GHz, 5 GHz

×




  • New

Detailed Specifications

Netgear EAX20-100NAS

Nighthawk AX1800 Dual‑Band Mesh Wi‑Fi Extender

The NETGEAR EAX20 AX1800 mesh extender boosts your existing Wi‑Fi 6 network across medium-sized homes (up to ~1,500 sq ft). It delivers seamless roaming, strong dual-band throughput, and multiple Gigabit ports for connected devices—all with plug-and-play ease.

Features

With Wi‑Fi 6 enhancements such as OFDMA, MU‑MIMO, and 160 MHz channels, the EAX20 delivers up to 1.8 Gbps aggregate speed. It integrates into your network using the same SSID and password to eliminate dead zones while roaming. Desktop-design offers flexibility—plus a wired backhaul option for maximum performance.

Advanced Options

Its four auto-sensing Gigabit ports support consoles, PCs, or allow wired uplinks from the router. A powerful 1.5 GHz dual-core processor ensures smooth handling of multiple streams for 4K streaming and gaming sessions.

Product Key Features

  •  AX1800 Wi‑Fi 6 performance (600 Mbps @2.4 GHz + 1,200 Mbps @5 GHz), with 4-stream OFDMA & MU‑MIMO

  •  Smart Roaming / seamless mesh, supports your router’s SSID for unified coverage

  •  4 Gigabit Ethernet ports for wired devices or wired-backhaul setups

  •  Dual‑core 1.5 GHz CPU, optimized for 4K/UHD streaming & gaming

  •  128‑bit AES Wi‑Fi security, backward compatible with all Wi‑Fi standards

  •  Nighthawk App setup, WPS support, LED controls, and optional wired router mode

Reliability & Performance

Reviewers label the EAX20 "the fastest extender" with impressive real-world speeds: ~375 Mbps at 15 ft, ~124 Mbps across 40 ft, and ~173 Mbps between floors Users report stable connections, ease of setup, and top-tier performance, though the extender’s size and price are noted considerations .

Key Features :

    • AX1800 dual-band Wi‑Fi 6 (600 + 1200 Mbps)

    • OFDMA, MU‑MIMO 4‑stream & 160 MHz channel support

    • Dual‑core 1.5 GHz processor

    • Wi‑Fi EasyMesh & Smart Roaming

    • 4 × Gigabit Ethernet ports

    • Nighthawk App setup, WPS, LED toggle

SpecificationDetail
Model Number EAX20‑100NAS
Product Type AX1800 Dual‑Band Mesh Wi‑Fi Extender
Wi‑Fi Standard IEEE 802.11ax (Wi‑Fi 6)
Max Speeds Up to 1.8 Gbps combined (600 + 1200)
Streams 4‑stream OFDMA/MU‑MIMO
Channel Width 160 MHz capable
Processor Dual-core 1.5 GHz
Ethernet Ports 4 × 10/100/1000 Mbps auto-sensing
Security WPA/WPA2-PSK, 128-bit AES
Mesh Support Smart Roaming, EasyMesh compatible
Setup Nighthawk App or browser, WPS, LED on/off feature
Physical (H×W×D) 241.7 × 169.5 × 63.4 mm (9.5 × 6.7 × 2.5 in)
Weight 1.1 lb (504 g)
