The Ergotron60-593-216 StyleView Vertical Lift is a wall-mounted computer workstation designed for busy environments where space efficiency and ergonomic adjustment are important. Its white finish, adjustable monitor mount, and fold-down keyboard tray make it suitable for work areas that need to remain compact when the workstation is not in use.
Key Features
- Space-saving wall mount: Folds into a compact profile of approximately 4 inches (10.2 cm) from the wall when the keyboard tray is stowed.
- 9-inch vertical adjustment: Provides approximately 23 cm of smooth height adjustment for users of different heights.
- Fold-down keyboard tray: Features adjustable negative tilt from 0° to -10° for a more comfortable typing position.
- Flexible cable management: The integrated system can be configured on either side to keep cables organized.
- Durable construction: Steel construction and an easy-to-clean exterior support use in demanding work environments.
Space-Efficient Workstation Design
The StyleView Vertical Lift is designed for space-constrained and high-traffic areas. The keyboard tray folds away when not required, helping reduce the workstation's projection from the wall and keeping surrounding areas more accessible.
The counterbalance mechanism enables smooth vertical adjustment. The keyboard tray includes a mouse pad, wrist rest, and mouse pouch to support everyday computer use.
Display Compatibility and Load Capacity
The workstation supports displays with VESA MIS-D mounting patterns of 75 × 75 mm or 100 × 100 mm. Displays up to 24 inches are recommended. Larger displays or unusually thick monitors may prevent the keyboard tray from folding completely flat.
The total supported load is 5–30 lb (2.3–13.6 kg), including the monitor and items placed on the keyboard tray. The monitor itself must not exceed 25 lb (11.3 kg). Monitor thickness greater than 3 inches (7.6 cm) may reduce the available capacity.
Product Specifications
| Brand | Ergotron |
|---|
| Part Number / MPN | 60-593-216 |
|---|
| Product Type | Wall-Mounted Vertical Lift Workstation |
|---|
| Product Series | StyleView |
|---|
| Model Configuration | High-Traffic Areas |
|---|
| Color | White |
|---|
| Construction | Steel |
|---|
| Mounting Type | Wall mount |
|---|
| Vertical Adjustment | 9 in (23 cm) |
|---|
| Keyboard Tray Tilt | 0° to -10° |
|---|
| Recommended Display Size | Up to 24 in |
|---|
| Total Load Capacity | 5–30 lb (2.3–13.6 kg), including monitor and keyboard-tray contents |
|---|
| Maximum Monitor Weight | 25 lb (11.3 kg) |
|---|
| VESA Compatibility | MIS-D, 75 × 75 mm and 100 × 100 mm |
|---|
| Cable Management | Integrated, configurable on either side |
|---|
| Included Accessories | Mouse pad, wrist rest, and mouse pouch |
|---|
| Shipping Dimensions | 39.5 × 16 × 10.75 in (1000 × 406 × 273 mm) |
|---|
| Shipping Weight | 36.4 lb (16.5 kg) |
|---|
| Warranty | 5 years |
|---|
Frequently Asked Questions
What is the Ergotron 60-593-216 designed for?
It is a wall-mounted computer workstation intended for space-constrained and high-traffic environments where a fold-away keyboard tray and adjustable display position are useful.
How much vertical adjustment does it provide?
The workstation provides approximately 9 inches (23 cm) of vertical adjustment.
Which monitors are compatible?
Compatible displays must support VESA 75 × 75 mm or 100 × 100 mm mounting. Displays up to 24 inches are recommended, and monitor dimensions should be checked to ensure the keyboard tray can fold flat.
What is the maximum supported weight?
The total load capacity is 30 lb (13.6 kg), including the monitor and keyboard-tray contents. The monitor itself must not exceed 25 lb (11.3 kg).
What accessories are included?
The listed package includes a mouse pad, wrist rest, and mouse pouch.
DC Supplies Product Note
Before ordering, verify the monitor's weight, thickness, and VESA pattern. Remember that the stated total load capacity includes the monitor and items placed on the keyboard tray. Ensure the wall structure and installation method are appropriate for the complete workstation.
