Ergotron 45-354-026 – LX Sit-Stand Wall Mount Keyboard Arm, Polished Aluminum
Overview
The Ergotron 45-354-026 is an LX Sit-Stand Wall Mount Keyboard Arm designed to provide an ergonomic keyboard and mouse platform for seated or standing workstations. The polished aluminum arm mounts to a sturdy vertical surface and provides adjustable positioning while keeping the keyboard workspace clear of the desk or floor.
The arm uses Ergotron Constant Force technology for smooth height and positioning adjustments. It provides a 20-inch (51 cm) height range and extends the keyboard tray up to 42 inches (107 cm), allowing users to position the keyboard for different working heights and then fold it away when not in use.
Technical Information
The 45-354-026 supports a keyboard and mouse load of up to 5 lb (2.3 kg). The arm provides 20 inches (50.8 cm) of vertical adjustment and 360° pan movement. The keyboard tray can extend up to 42 inches (107 cm) from the wall.
The ergonomic keyboard tray measures 18.3 x 8.9 inches (46 x 23 cm), while the slide-out mouse tray measures 8 x 8 inches (20 x 20 cm). The mouse tray can slide out to either the left or right side according to user preference.
When the keyboard arm is in its lowered working position, the tray provides a 5° back-tilt. For storage, the keyboard tray folds upright through 90°, reducing its projection from the wall to approximately 5.8 inches (14.7 cm).
Compatibility
The Ergotron 45-354-026 is designed for keyboard and mouse workstation applications where a wall-mounted sit-stand platform is required. It attaches directly to sturdy vertical surfaces and can also be installed to a compatible Ergotron Wall Track using the separately available 97-091 bracket.
The arm is particularly suited for use alongside a compatible Ergotron LCD mounting arm. Ergotron identifies the 45-354-026 as the sit-stand keyboard component for creating a complete wall-mounted workstation with compatible display mounting hardware.
Key Features
- 20-inch (51 cm) height adjustment for seated-to-standing keyboard positioning.
- Extends the keyboard tray up to 42 inches (107 cm) from the wall.
- Supports keyboard and mouse equipment up to 5 lb (2.3 kg).
- Ergonomic 5° back-tilt keyboard tray with slide-out mouse tray and wrist rest.
- Polished aluminum construction, Constant Force technology and 10-year warranty.
Applications
The Ergotron 45-354-026 is suitable for wall-mounted workstations, healthcare and clinical environments, control rooms, offices, laboratories, industrial work areas and other space-constrained applications requiring an adjustable keyboard and mouse platform. Its ability to fold close to the wall makes it useful where the workstation needs to be stored or cleared when not in use.
DC Supplies Product Note
The exact MPN 45-354-026 identifies the LX Sit-Stand Wall Mount Keyboard Arm in polished aluminum. It is a keyboard/mouse mounting arm, not an LCD display arm. Ergotron separately identifies 45-353-026 as the LX Sit-Stand Wall Mount LCD Arm and 45-383-026 as the LX HD Sit-Stand Wall Mount LCD Arm.
Specifications
| Brand | Ergotron |
|---|
| Part Number | 45-354-026 |
|---|
| Product Type | LX Sit-Stand Wall Mount Keyboard Arm |
|---|
| Color / Finish | Polished aluminum |
|---|
| Mounting Type | Wall mount |
|---|
| Recommended Use | Keyboard and mouse |
|---|
| Weight Capacity | Up to 5 lb (2.3 kg) |
|---|
| Height Adjustment | 20 in (50.8 cm) |
|---|
| Maximum Extension | 42 in (107 cm) |
|---|
| Folded Projection | 5.8 in (14.7 cm) |
|---|
| Pan | 360° |
|---|
| Keyboard Tray Tilt | 5° back-tilt in working position |
|---|
| Storage Position | 90° upright fold |
|---|
| Keyboard Tray Dimensions | 18.3 x 8.9 in (46 x 23 cm) |
|---|
| Mouse Tray Dimensions | 8 x 8 in (20 x 20 cm) |
|---|
| Mounting Options | Sturdy vertical surfaces; Ergotron Wall Track with 97-091 bracket |
|---|
| Material | Aluminum |
|---|
| Product Weight | 14.4 lb (6.5 kg) |
|---|
| Shipping Dimensions | 22.4 x 13.7 x 7.8 in (57 x 35 x 20 cm) |
|---|
| Shipping Weight | 17.1 lb (7.8 kg) |
|---|
| Warranty | 10 years |
|---|
FAQs
What is the Ergotron 45-354-026?
The 45-354-026 is an Ergotron LX Sit-Stand Wall Mount Keyboard Arm for positioning a keyboard and mouse at adjustable seated or standing heights.
What is the maximum load capacity?
The keyboard arm supports up to 5 lb (2.3 kg) of keyboard and mouse equipment.
How much height adjustment does it provide?
The arm provides 20 inches (50.8 cm) of vertical height adjustment.
How far can the keyboard extend from the wall?
The keyboard tray can extend up to 42 inches (107 cm) from the wall.
What are the keyboard tray dimensions?
The keyboard tray measures 18.3 x 8.9 inches (46 x 23 cm).
Does the mouse tray support left- or right-side positioning?
Yes. The slide-out mouse tray can be positioned on either the left or right side according to user preference.
Can the keyboard arm fold away?
Yes. The keyboard tray folds upright 90° for storage and reduces its projection to approximately 5.8 inches (14.7 cm) from the wall.
Can the 45-354-026 be mounted to an Ergotron Wall Track?
Yes. A 97-091 bracket is required for Wall Track installation and is ordered separately.
Does it include cable management?
Yes. The design routes cables underneath the arm to keep them organized and away from the working area.
What is the warranty?
The 45-354-026 is specified with a 10-year warranty by the product documentation and distributor listings.
