Eaton SRWALLBRKT2U - 2U Vertical Wall-Mount Rack Bracket 175 lb

Overview :

The Eaton SRWALLBRKT2U is a vertical wall-mount rack bracket designed to secure 2U of 19-inch rack-mount equipment directly to a wall surface without a full cabinet. It is deployed by network engineers, facilities technicians, and small-business IT teams where floor-standing racks are impractical or space-constrained. This open-frame bracket addresses the need for robust, low-footprint mounting of essential IT gear such as switches, UPS modules, or compact servers.

From a deployment perspective, the bracket features cold-rolled steel construction with a durable black powder-coat finish and is compatible with standard EIA-310-E 19-inch rack-mount equipment. It supports up to 175 lb (79.4 kg) of static load, accommodating heavy power and network devices. Mounting holes are spaced 16 inches on center to align with common stud spacing for secure installation. Bracket rails support square-hole mounting, with included hardware for fast attachment.

This bracket fits at the edge and distribution layers of infrastructure, such as telecommunications closets, back offices, lab spaces, and utility rooms. It is suitable for light production or test environments where enclosed racks are not required, and where wall mounting delivers cable-clear access and serviceability. The open design affords unrestricted access to cabling and connectors once gear is installed.

Integration aligns with 19-inch EIA-standard equipment racks and SmartRack accessories. The bracket can be installed vertically on walls or horizontally beneath benches/work surfaces to support two rack units of equipment. User-supplied anchors are required to attach to structural surfaces, and included hardware secures mounted devices to the bracket's rails.

In a practical deployment, a network technician might use the SRWALLBRKT2U to mount a compact PoE switch and small UPS in a server closet where a full rack would obstruct HVAC access or floor space. It supports maintenance tasks by keeping power and network connections accessible while minimizing footprint.

This bracket should not be used where seismic ratings, lockable enclosures, or environmental protection (dust/water) are required. It is not suitable for applications demanding deep rack support (beyond shallow equipment) or where cable management panels and dress panels are mandatory.

Key Features

• 2U vertical wall-mount rack bracket for 19″ equipment
• Cold-rolled steel with black powder-coat finish
• 175 lb (79.4 kg) maximum static load capacity
• Holes spaced for standard 16″ stud mounting
• Compatible with most EIA-310-E 2-post rack gear
