Detailed Specifications
Logitech RCRALLYPLUS - Video Conferencing System
Overview
The Logitech Rally Plus System (RCRALLYPLUS / 960-001225) is an enterprise-grade, modular video conferencing solution engineered for large and extra-large boardrooms.This premium USB-connected hardware configuration provides IT infrastructure engineers and AV integrators with a scalable blueprint to unify multi-participant collaborative spaces while maintaining studio-quality optics and automated room acoustic coverage.
The standard architecture separates signal processing across a dedicated Table Hub and a Display Hub linked via a single structural Cat6A Ethernet run. This layout eliminates long, cluttered cable pathways across open corporate floors. The premium Pan-Tilt-Zoom (PTZ) camera mechanism captures sharp 4K Ultra-HD streams at 30 frames per second.It features an integrated 15x HD zoom matrix and advanced RightSense technologies to automate human figure tracking, facial light optimization, and active acoustic steering.
Designed to provide fluid plug-and-play operability with cloud-based computational setups, this hardware integrates natively with dedicated room platforms such as Microsoft Teams Rooms, Zoom Rooms, and Google Meet.Do not deploy this multi-component topology in small huddle rooms or micro-workspaces, as its expansive hardware footprint, dual high-output speakers, and long-range mic-pod daisy chains are architecturally optimized for deep, high-occupancy corporate layouts.
Key Features
Dual high-performance speakers decouple mechanically to isolate lens vibration.
Modular hubs communicate over a single Cat6A link up to 50 meters long.
RightSight camera intelligence automatically reframes and adjusts for team shifts.
RightSound matrix uses 56 distinct acoustic beams to isolate human speech.
Premium PTZ lens parks at -90° in sleep mode to ensure physical workspace privacy.
Specifications
| Specification Field | Verified Product Data |
| Brand | Logitech |
| Model SKU | RCRALLYPLUS / Rally Plus |
| Video Capture Resolution | 4K Ultra HD, 1440p, 1080p, 720p @ 30fps; 1080p/720p @ 60fps |
| Lens Zoom Matrix | 15x HD Zoom (5x Optical + 3x Digital) |
| Motorized Range parameters | Pan: ±90°, Tilt: +50° / -90° |
| Optical Field of View | Diagonal: 90°, Horizontal: 82°, Vertical: 52° |
| Microphones Included | 2 x RightSound Mic Pods (Daisy-Chainable up to 7 units) |
| Audio Pickup Radius | 23-foot (7-meter) diameter per individual Mic Pod |
| Speakers Included | 2 x High-Performance 3" Speakers with Rare-Earth Magnets |
| Companion Hardware | RF Remote Control (Direct line-of-sight not required) |
