Detailed Specifications
Eaton U280-001-W2-HG Hospital-Grade USB-A Wall Charger 2.5 A
Overview :
The Eaton U280-001-W2-HG is a single-port USB-A wall charger certified for use in patient-care vicinities and medical environments. It is used by healthcare facilities, clinics, and IT infrastructure teams to provide safe USB power for smartphones, tablets, and USB-powered devices in areas where electrical safety standards are stringent. The product addresses the need for medically compliant charging without external adapters or non-rated consumer chargers.
Designed as a compact AC/DC adapter, this charger accepts 100-240 V AC input and delivers up to 5.2 V DC at 2.5 A (13 W) from a single USB-A port. It features built-in overload and overcharge protection that terminates charging when a device's battery is full and protects against overcurrent and overheating.
Mechanically, the unit plugs directly into a NEMA 1-15P fixed blade receptacle and includes a locking tab for secure permanent mounting to a wall outlet plate where code compliance or theft prevention is required. Its compact white enclosure is suitable for tight spaces often found in corridors, patient rooms, nursing stations, or remote offices.
This charger meets UL 60601-1 and associated AAMI/CSA standards for medical electrical equipment, making it appropriate for patient-care areas where isolation from mains and shock risk reduction are mandated. It does not provide network connectivity, data interfaces, or intelligent power management.
A typical deployment is permanent installation in hospital rooms or clinical waiting areas to offer compliant USB charging for patient or staff devices. It is not intended for powering high-current loads, industrial power distribution, or as an IT infrastructure power source beyond USB device charging.
Key Features
- UL 60601-1 hospital-grade certification for patient-care vicinities
- Single USB-A port with 5.2 V 2.5 A (13 W) output
- Built-in protection vs overcurrent, overheat, overcharge
- NEMA 1-15P fixed blade wall plug with locking tab
- Compact white enclosure for wall-outlet install
Technical Specifications
| Specification | Detail |
|---|
| Brand | Eaton |
| Part Number | U280-001-W2-HG |
| Product Type | Hospital-Grade USB Wall Charger |
| Input Voltage | 100-240 V AC, 50/60 Hz |
| Output Voltage | 5.2 V DC |
| Output Current | 2.5 A |
| Output Power | 13 W |
| Charging Ports | 1 × USB-A |
| Input Connector | NEMA 1-15P fixed blades |
| Certifications | UL 60601-1 medical, CSA, RoHS, WEEE |
| Protection | Overcurrent, overcharge, overheat |
| Locking Tab | Yes, for wall outlet plate |
| Operating Temp | ~0 °C to 40 °C |
| Storage Temp | ~-40 °C to 80 °C |
| Relative Humidity | 0-95 % non-condensing |
| Housing | White plastic enclosure |
| Weight | ~0.15 lb (~68 g) |
| Dimensions | ~2.80″ × 1.24″ × 1.16″ |
