Detailed Specifications
Eaton BC350RNC 350VA 210W 120V Standby Cloud-Connected UPS
Overview
The Eaton BC350RNC is a 350VA / 210W standby UPS designed for protecting low-power edge electronics, POS systems, desktop workstations, routers, and networking devices from short-duration outages, surges, and voltage instability.
It combines battery backup protection with cloud-connected remote monitoring through Eaton Brightlayer integration, enabling centralized visibility and alerting for distributed deployments.
The unit provides three NEMA 5-15R battery-backed outlets with 120V output and supports remote monitoring through Ethernet connectivity, NFC-assisted provisioning, and browser/mobile access.
Deployment is suited for retail locations, kiosks, branch offices, industrial edge systems, and small IT environments where remote UPS management reduces maintenance visits and downtime exposure.
This model is not intended for high-density rack deployments, large servers, or extended runtime applications.
Key Features
- 350VA standby UPS with 210W backup capacity
- Cloud-connected monitoring via Brightlayer platform
- Three battery-backed NEMA 5-15R output receptacles
- NFC-assisted network configuration simplifies deployment
- Compact housing supports desktop or wall mounting
Specifications
| Parameter | Value |
|---|
| Brand | Eaton |
| Part Number | BC350RNC |
| Product Type | Cloud-Connected Standby UPS |
| UPS Topology | Standby |
| Capacity | 350 VA / 210 W |
| Input Voltage | 120 VAC |
| Output Voltage | 120 VAC |
| Output Waveform | Sine wave (AC mode), PWM sine wave (battery mode) |
| Input Plug | NEMA 5-15P |
| Output Receptacles | 3 × NEMA 5-15R |
| Input Frequency | 50/60 Hz |
| Transfer Time | <10 ms |
| Runtime at Half Load | 7 minutes |
| Runtime at Full Load | 2 minutes |
| Battery Type | Sealed lead-acid (VRLA) |
| Recharge Time | 8 hours |
| Network Connectivity | Ethernet + NFC |
| Form Factor | Desktop / wall mount |
| Surge Protection | 190 joules |
| Operating Temperature | 32°F to 122°F (0°C to 50°C) |
| Certifications | UL 1778, CSA, FCC Class B, RoHS |
| Compliance | ENERGY STAR |
