Detailed Specifications
APC SRT48RMBP - 48V Rackmount Battery Pack for Smart-UPS 1/1.5 kVA
Overview :
The APC SRT48RMBP is an external rackmount battery pack designed to extend backup runtime for compatible APC Smart-UPS On-Line 1 kVA and 1.5 kVA units that use a 48 V DC battery bus. It is deployed by IT operations and data center teams to scale UPS runtime for critical loads during utility outages, enabling orderly shutdown and increased uptime.
This external pack uses sealed lead-acid (VRLA) battery technology with maintenance-free, leak-proof construction and hot-swappable modules to support service without interrupting connected loads.
Packaged in a 2 U rackmount form factor, the SRT48RMBP integrates rack mounting brackets and documentation to simplify installation in standard 19″ server racks beside the UPS.
Physical dimensions and weight are optimized for dense rack environments while supporting predictable runtime scaling when chained with additional battery packs. Up to 10 battery packs can be added to tailor runtime based on load requirements.
Expected service life of the battery modules is 3 - 5 years under normal operating conditions; battery performance depends on temperature, load, and charging cycles.
Key Features :
• 48 V DC external battery pack for extended UPS runtime
• Maintenance-free VRLA batteries with hot-swap support
• 2 U rackmount form factor for 19″ cabinets
• Supports chaining up to 10 packs for scalable runtime
• Includes rack brackets and documentation
Specifications :
| Specification | Value |
|---|
| Brand | APC by Schneider Electric |
| Part Number | SRT48RMBP |
| Product Type | External UPS Battery Pack / Runtime Extension |
| Battery Voltage | 48 V DC |
| Battery Technology | Sealed Lead-Acid (VRLA) |
| Rack Height | 2 U |
| Form Factor | Rackmount |
| Height | 85 mm (3.35 in) |
| Width | 432 mm (17.01 in) |
| Depth | 536 mm (21.10 in) |
| Net Weight | ~29.9 kg (65.9 lb) |
| Hot-Swappable | Yes |
| Expected Battery Life | 3 - 5 years |
| Operating Temp. Range | 0 - 40 °C (32 - 104 °F) |
| Operating Humidity | 0 - 95 % non-condensing |
| Certifications | RoHS compliant |
