Ubiquiti UDR7 UniFi Dream Router 7 WiFi 7 10G Cloud Gateway
Overview
The Ubiquiti UDR7 is the UniFi Dream Router 7, a compact desktop cloud gateway combining routing, security, WiFi 7, switching, and the full UniFi application suite in one device. It provides integrated tri-band 2.4 GHz, 5 GHz, and 6 GHz WiFi 7, a 10G SFP+ WAN interface, a 2.5 GbE RJ45 WAN interface, and three 2.5 GbE RJ45 LAN ports including one PoE port. Ubiquiti specifies 2.3 Gbps IDS/IPS throughput and support for 30+ managed UniFi devices. :contentReference[oaicite:0]{index=0}
WiFi 7 Connectivity
The integrated access point supports 802.11a/b/g/n/ac/ax/be standards across the 2.4 GHz, 5 GHz, and 6 GHz bands. Ubiquiti specifies maximum wireless throughput of 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz, and 5.7 Gbps on 6 GHz. Each radio uses 2x2 DL/UL MU-MIMO, with antenna gains of 5 dBi at 2.4 GHz, 7 dBi at 5 GHz, and 6 dBi at 6 GHz. :contentReference[oaicite:1]{index=1}
WAN, LAN, and PoE
The UDR7 provides two WAN options: one 10G SFP+ port and one 2.5 GbE RJ45 port. Three additional 2.5 GbE RJ45 LAN ports are provided, with one supporting PoE output. The integrated PoE port provides a 15.4W PoE budget and supports 44–57V PoE operation. :contentReference[oaicite:2]{index=2}
UniFi Applications and Storage
The UDR7 supports the full UniFi application suite, including Network, Protect, Access, Talk, and Connect. A 64GB microSD card is pre-installed for NVR storage, and the device includes a microSD expansion slot. Ubiquiti specifies capacity for up to five HD, two 2K, or one 4K managed camera. :contentReference[oaicite:3]{index=3}
Routing, Security, and VPN
The gateway supports stateful firewall functions, application-aware Layer 7 firewall controls, DPI and traffic identification, zone-based firewalling, advanced filtering, intrusion prevention and detection, ad blocking, VLAN/subnet traffic segmentation, advanced NAT, customizable DHCP, IPv6 ISP support, OSPF, advanced QoS, multicast DNS, and multi-WAN load balancing. VPN and SD-WAN functions include Site Magic, IPsec, OpenVPN, WireGuard, and Teleport. :contentReference[oaicite:4]{index=4}
Key Features
- Integrated tri-band WiFi 7 with 6 GHz support
- 10G SFP+ and 2.5 GbE RJ45 WAN connectivity
- Three 2.5 GbE LAN ports including one 15.4W PoE port
- Full UniFi application suite with pre-installed 64GB microSD storage
- 2.3 Gbps IDS/IPS throughput with support for 30+ managed UniFi devices
Applications
The UDR7 is designed for small-space deployments that require an integrated gateway, wireless access point, Ethernet switching, security services, and UniFi application hosting. Its 10G SFP+ interface can be used for high-speed WAN or LAN connectivity, while the 2.5 GbE ports provide multi-gigabit wired connections for compatible network devices.
DC Supplies Product Note
The UDR7 uses an internal 50W AC/DC power supply and can provide up to 15.4W of PoE output on its designated PoE port. The stated 26W maximum system consumption excludes PoE output, so deployments using the PoE port should account for the additional connected-device power requirement when planning the available power budget. :contentReference[oaicite:5]{index=5}
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | UDR7 |
| Product Type | Desktop Cloud Gateway with Integrated WiFi 7 |
| Product Name | UniFi Dream Router 7 |
| Managed UniFi Devices | 30+ |
| IDS/IPS Throughput | 2.3 Gbps |
| WiFi Standard | 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
| WiFi Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Maximum 2.4 GHz Throughput | 688 Mbps |
| Maximum 5 GHz Throughput | 4.3 Gbps |
| Maximum 6 GHz Throughput | 5.7 Gbps |
| Default WAN Ports | 1 × 10G SFP+; 1 × 2.5 GbE RJ45 |
| LAN Ports | 3 × 2.5 GbE RJ45, including 1 × PoE |
| PoE Budget | 15.4W |
| PoE Voltage Range | 44–57V DC |
| NVR Storage | 64GB pre-installed microSD |
| Expansion Storage | microSD card slot |
| Maximum Power Consumption | 26W, excluding PoE output |
| Power Method | Universal AC input, 100–240V AC, 1.5A maximum, 50/60 Hz |
| Power Supply | Internal 50W AC/DC |
| Processor | Quad-core ARM Cortex-A53 at 1.5 GHz |
| System Memory | 3GB |
| Dimensions | 110 × 184.1 mm (4.3 × 7.3") |
| Weight | 1.1 kg (2.4 lb) |
| Enclosure Material | Polycarbonate |
| LCM Display | 0.96-inch status display |
| Operating Temperature | -10 to 40°C (14 to 104°F) |
| Operating Humidity | 5–95% noncondensing |
| Certifications | CE, FCC, IC |
Frequently Asked Questions
What WiFi standard does the UDR7 support?
The UDR7 supports WiFi 7 across integrated 2.4 GHz, 5 GHz, and 6 GHz radios, while maintaining compatibility with earlier 802.11 standards listed by Ubiquiti. :contentReference[oaicite:6]{index=6}
What WAN connections are available?
The UDR7 provides one 10G SFP+ WAN interface and one 2.5 GbE RJ45 WAN interface. Ubiquiti also supports WAN/LAN use of the high-speed interfaces depending on configuration. :contentReference[oaicite:7]{index=7}
Does the UDR7 provide PoE?
Yes. One of its three 2.5 GbE LAN ports supports PoE with a total PoE budget of 15.4W. :contentReference[oaicite:8]{index=8}
Does the UDR7 include storage?
Yes. Ubiquiti specifies a pre-installed 64GB microSD card for NVR storage, and the device includes a microSD expansion slot. :contentReference[oaicite:9]{index=9}
Which UniFi applications can run on the UDR7?
The UDR7 supports the full UniFi application suite, including Network, Protect, Access, Talk, and Connect. :contentReference[oaicite:10]{index=10}
What is the UDR7's IDS/IPS throughput?
Ubiquiti specifies 2.3 Gbps IDS/IPS throughput for the UDR7. :contentReference[oaicite:11]{index=11}
