Detailed Specifications
HPE AFBR-57F5AMZ-HP3 16GFC 850 nm SFP+ Transceiver
Overview
The HPE AFBR-57F5AMZ-HP3 is a short-wave SFP+ transceiver module designed for 16 Gb Fibre Channel SAN links over multimode fiber. It operates at 850 nm and supports link distances up to 100 meters on OM3/OM4 fiber. The module fits in standard SFP+ ports and provides digital diagnostics (DOM) for real-time monitoring of optical parameters, making it suitable for use in enterprise SAN switches, HBAs, or storage arrays.
Key Features
16 Gb/s Fibre Channel (16GFC) signalling rate
850 nm VCSEL transmitter for multimode fiber
Duplex LC connector for standard fiber cabling
SFP+ form factor, hot-pluggable
Digital optical monitoring (DOM) for diagnostics
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE |
| Part Number | AFBR-57F5AMZ-HP3 |
| Product Type | 16G Fibre Channel SFP+ Transceiver |
| Data Rate | 16 Gb/s |
| Supported Speeds | 16GFC, 8GFC, 4GFC |
| Wavelength | 850 nm |
| Fiber Type | Multimode fiber (MMF) |
| Maximum Reach | 100 meters MMF |
| Connector | Duplex LC |
| Form Factor | SFP+ small-form factor pluggable |
| Digital Monitoring | Yes (SFF-8472) |
| Power Supply | 3.3 V |
| Operating Temperature | 0 °C to 70 °C |
| Compliance | ANSI Fibre Channel FC-PI-5, SFP+ MSA, RoHS |
| Applications | SAN switching, host bus adapters, storage array links |
