Ergotron 45-383-026 – LX HD Sit-Stand Wall Mount LCD Arm, Polished Aluminum
Overview
The Ergotron 45-383-026 is an LX HD Sit-Stand Wall Mount LCD Arm designed for large displays, mid-sized televisions and compatible all-in-one computers. The polished aluminum arm provides a 20-inch (51 cm) vertical adjustment range for comfortable seated or standing use while mounting directly to a sturdy vertical wall surface.
The system combines the LX HD sit-stand arm, extension, wall-mount base and VESA brackets. Its Constant Force motion technology provides smooth height adjustment, while the wall-mounted design allows the display to be moved away from the wall when required and folded closer to the wall when not in use.
Technical Information
The 45-383-026 supports displays weighing 14–30 lb (6.3–13.6 kg), with monitor depth potentially affecting the applicable weight capacity. Ergotron specifies a typical display size of up to 46 inches. The arm provides 20 inches (51 cm) of vertical adjustment and extends the display up to 33 inches (84 cm).
The display can tilt 75° upward and 5° downward, providing an 80° total tilt range. The arm provides 360° pan capability, while the display rotation is limited to 90°. A rotation stop at the wall-mount base limits the extension-to-base connection to 180° to prevent the extension from contacting the wall.
The VESA interface supports MIS-D, MIS-E and MIS-F mounting standards, including 75 x 75 mm, 100 x 100 mm, 200 x 100 mm and 200 x 200 mm mounting patterns. An optional Ergotron 97-759 VESA Bracket Adapter Kit can extend MIS-F compatibility to 400 x 200 mm, 400 x 300 mm and 400 x 400 mm patterns.
Compatibility
The Ergotron 45-383-026 is designed for compatible LCD displays, large monitors, mid-sized TVs and all-in-one computers that meet the specified weight and VESA mounting requirements. The manufacturer's 46-inch display rating is a typical size guideline; the display may exceed that diagonal size provided its weight remains within the mount's specified capacity.
The mount attaches directly to a sturdy vertical surface using the supplied wall-mount base. The base also incorporates theft-deterrent anchor holes for compatible cable locks. Optional accessories can expand the VESA mounting range where required.
Key Features
- Supports displays weighing 14–30 lb (6.3–13.6 kg).
- 20-inch (51 cm) vertical adjustment supports seated-to-standing display positioning.
- Extends the display up to 33 inches (84 cm) from the wall with 360° arm pan.
- Supports VESA MIS-D, MIS-E and MIS-F mounting patterns including 75/100/200 mm interfaces.
- Polished aluminum construction with Constant Force technology and a 10-year warranty.
Applications
The Ergotron 45-383-026 is suitable for professional workstations, control rooms, meeting spaces, digital signage, healthcare environments, industrial work areas and other installations requiring a large display with flexible sit-stand positioning. Its direct wall-mount configuration also helps preserve floor and desk space while allowing the display to be repositioned as required.
DC Supplies Product Note
The exact MPN 45-383-026 identifies the LX HD Sit-Stand Wall Mount LCD Arm with wall-mount base in polished aluminum. It should not be substituted with the closely related 45-384-026, which uses a desk clamp/grommet mounting configuration. The 45-383-026 is specifically the wall-mount version.
Specifications
| Brand | Ergotron |
|---|
| Part Number | 45-383-026 |
|---|
| Product Type | LX HD Sit-Stand Wall Mount LCD Arm |
|---|
| Color / Finish | Polished aluminum |
|---|
| Mounting Type | Wall mount |
|---|
| Typical Display Size | Up to 46 in |
|---|
| Weight Capacity | 14–30 lb (6.3–13.6 kg) |
|---|
| Vertical Adjustment | 20 in (51 cm) |
|---|
| Maximum Extension | 33 in (84 cm) |
|---|
| Folded Depth | 4.5 in (11.4 cm) |
|---|
| Tilt | 80° total; 75° up / 5° down |
|---|
| Pan | 360° |
|---|
| Display Rotation | 90° |
|---|
| VESA Standard | MIS-D / MIS-E / MIS-F |
|---|
| VESA Mounting Patterns | 75 x 75, 100 x 100, 200 x 100, 200 x 200 mm |
|---|
| Optional VESA Expansion | 400 x 200, 400 x 300, 400 x 400 mm with optional 97-759 adapter |
|---|
| Motion Technology | Constant Force |
|---|
| Quality Testing | 10,000-cycle lift mechanism test |
|---|
| Product Weight | 13.5 lb (6.1 kg) |
|---|
| Shipping Dimensions | 22 x 11 x 7.5 in (56 x 28 x 19 cm) |
|---|
| Warranty | 10 years |
|---|
FAQs
What is the Ergotron 45-383-026?
The 45-383-026 is the Ergotron LX HD Sit-Stand Wall Mount LCD Arm in polished aluminum, designed for large displays requiring flexible height and viewing-position adjustment.
What is the maximum display weight?
The specified display capacity is 14–30 lb (6.3–13.6 kg). Monitor depth can affect the applicable weight capacity.
What size display does it support?
Ergotron specifies a typical display size of up to 46 inches. Display size is a guideline; the display must remain within the mount's specified weight and mounting limits.
How much height adjustment does the arm provide?
The arm provides 20 inches (51 cm) of vertical adjustment, allowing the display to be positioned for seated or standing use.
How far can the display extend from the wall?
The arm can extend the display up to 33 inches (84 cm). When folded, the arm reaches approximately 4.5 inches (11.4 cm) from the wall.
What VESA mounting patterns are supported?
The mount supports VESA MIS-D, MIS-E and MIS-F interfaces, including 75 x 75 mm, 100 x 100 mm, 200 x 100 mm and 200 x 200 mm mounting patterns.
Can larger VESA patterns be supported?
Yes. The optional Ergotron 97-759 VESA Bracket Adapter Kit supports MIS-F patterns of 400 x 200 mm, 400 x 300 mm and 400 x 400 mm.
How much can the display tilt?
The display provides 75° of upward tilt and 5° of downward tilt, for an 80° total tilt range.
Does the arm rotate the display?
Yes. The display has 90° rotation capability. The arm itself provides 360° pan movement, with a wall-base rotation stop limiting the extension-to-base connection to 180° to help prevent contact with the wall.
What is included with the 45-383-026?
The package includes the LX HD sit-stand arm, extension, wall-mount base and VESA brackets.
What warranty does the 45-383-026 have?
The Ergotron 45-383-026 has a 10-year warranty.
