Netgear AVB4248P-10000S AVB License for AV Line M4250-40G8F-PoE+ Network Switch

Overview AVB4248P-10000S:

Introducing the NETGEAR AVB4248P-10000S AV Line of M4250 Switches, AVB4248P-10000S developed and engineered for audio/video professionals with dedicated service and support.

M4250 AVB4248P-10000S has been built from the ground up for the growing AV over IP market, combining years of networking expertise in AV with M4300 and M4500 series with best practices from leading experts in the professional AV market. AV codecs generally use 1Gbps or 10Gbps per stream and the AV Line of M4250 targets the widespread 1Gbps codecs.

PoE+, Ultra90 PoE++, and rear-facing ports ensure a clean integration in AV racks. AVB4248P-10000S M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately. For video, the AVB4248P-10000S M4250 offers profiles for NVX, AMX, AVB4248P-10000S Q-SYS, NDI, Dante, etc. as well as audio/ video/control mixed profiles. When multiple switches are used, NETGEAR AVB4248P-10000S IGMP PlusTM brings automation for you to just connect them together, or with M4300 and M4500 switches.

The Netgear AVB4248P-10000S GSM4248P-100NAS has 48 Ports:
40-port 10/100/1000BASE-T (RJ45) PoE+ with 480W PoE budget
8-port 1000BASE-X (SFP)

  • Features AVB4248P-10000S:

    • 40-port 10/100/1000BASE-T (RJ45) PoE+ with 480W PoE budget
    • 8-port 1000BASE-X (SFP)
    • 96 Gbps non-blocking fabric across 48 ports
    • Out-of-band 1G Ethernet management port
    • USB-C and RJ45 RS232 console ports and USB-A storage port
    • Front black display panel and all ports in the back
    • Possible reversed mounting with ports in the front
    • Rack-mounting standard brackets
    • Longer brackets for recessed mounting (2 inches / 5 cm)
    • Threaded hole in front (1xM10) for clamps
    • Threaded holes on the bottom (4xM5) for 50x100mm VESA plates
    • Selectable fan modes for fanless, quiet, or cool operation
  • Specifications AVB4248P-10000S:

    • Primary Port Speed: 1 Gigabit
    • Number of Ports: 48 (40x 1G PoE+, 8x SFP)
    • PoE Ports / Budget: 40 PoE+ (30W/port), 480W Budget
    • IGMP Support: Enhanced (NETGEAR IGMP PlusT)
    • Jumbo Frame Support: Yes, up to 12kb
    • AVB Support: Yes. Electronic license required, activation key sent via email (AVB4248P-10000S).
    • Acoustics: Fanless or 47dB@25§C
    • Power Consumption: With PoE: 624.8W/2133.07Btu/hr; Without PoE: 59.5W/203.13Btu/hr; Standby without any
      port connection: 46.4W/158.41Btu/hr
    • Dimensions (WxDxH): 440 x 400 x 43.2 mm
    • Weight: 5.85Kg (12.9lb)
  • Item Includes AVB4248P-10000S:

    • 1x M4250-40G8F-PoE+ (GSM4230P)
    • 1x Power Cord(s)
    • 1x Console USB Type-C and RJ45-DB9 Cables
    • 1x Rack-Mounting Standard Brackets
    • 1x Longer Brackets for Recessed Mounting
    • 1x Rubber Footpads for Tabletop Installation
    • 1x Installation Guide
