HPE Aruba JL258A 2930F 8G PoE+ 2SFP+ Ethernet Switch

New

In Stock

HPE Aruba JL258A 2930F 8-Port Gigabit PoE+ Switch with SFP+

×




$542.90

  • New

Detailed Specifications

HPE JL258A

Aruba 2930F 8G PoE+ 2SFP+ Managed Ethernet Switch

The HPE Aruba JL258A 2930F 8G PoE+ 2SFP+ Switch is a smart-managed Layer 3 access switch tailored for SMBs, remote offices, or branch deployments. With eight PoE+ ports delivering up to 125 W and high-speed uplink flexibility via SFP+, it simplifies deployment of IP devices and uplinks in a compact, energy-efficient, and silent form factor.

Features :

Part of the Aruba 2930F family, the JL258A strikes a balance between advanced features and ease of use for networks that require robust performance without complexity. It supports key Layer 3 protocols—static routing, RIP, and Access OSPF—enabling efficient traffic segmentation and dynamic routing without additional licensing. Equipped with 8 auto-sensing Gigabit RJ-45 ports with PoE+ (125 W budget), it powers devices like cameras, APs, and VoIP phones. The two SFP+ 1/10 GbE uplinks provide high-capacity links to aggregation switches or servers.

Advanced Options :

Aruba's Virtual Switching Framework (VSF) allows stacking up to eight switches into a single logical device, simplifying management and scaling. . Zero Touch Provisioning adds remote deployability ease, perfect for branch setups managed via Aruba Central and AirWave. Its fanless, rack/desktop-friendly design ensures low-noise operation and efficient cooling within tight spaces, delivering enterprise-grade networking without disruption.

Product Key Features

  • 8× Gigabit RJ-45 PoE+ ports with 125 W total power budget

  • 2× SFP+ ports supporting 1/10 GbE uplinks

  • Layer 3 features including static routing, RIP, and Access OSPF

  • Fanless and rack/desktop mountable design

  • Smart-managed via web GUI, CLI, SNMP, AirWave, and Aruba Central

  • Zero Touch Provisioning and VSF stacking support for scalability


Reliability & Performance :

Built on Aruba’s ProVision ASIC, the JL258A delivers wire-speed forwarding (56 Gbps switching capacity, 41.7 Mpps forwarding rate) with deterministic latency (≈3.8 μs at 1 Gbps, 1.6 μs at 10 Gbps) Fanless cooling reduces maintenance and noise, while IEEE 802.1X, ACLs, storm control, and RADIUS/TACACS+ enhance security protocols. PoE power monitoring and EEE support reduce energy costs—ideal for always-on SMB environments.

Key Features :

  • 8× 10/100/1000Base-T PoE+ ports (125 W total)

  • 2× SFP+ (1/10 GbE) uplink ports

  • Layer 3: static, RIP, and Access OSPF routing

  • VSF stacking (up to 8 units) & Zero Touch Provisioning

  • Fanless, low-noise design suitable for rack or desktop deployment

  • Smart-managed via web GUI, CLI, SNMP, AirWave, Aruba Central

  • Advanced security: 802.1X, ACLs, RADIUS/TACACS+, port/mac lockout

Specifications :

SpecificationDetails
Model Number JL258A
Product Series Aruba 2930F
Ports 8 × 10/100/1000Base-T PoE+
PoE Budget 125 W (IEEE 802.3at)
SFP+ Uplink Ports 2 × 1/10 GbE
Switching Capacity 56 Gbps
Forwarding Rate 41.7 Mpps
Latency 3.8 μs (1 Gbps), 1.6 μs (10 Gbps)
Layer Support Layer 2 + Layer 3 (static, RIP, Access OSPF)
Stacking VSF, up to 8 units
Management Web GUI, CLI, SNMP, Aruba Central, AirWave
Power Internal (100–240 VAC, fanless)
Dimensions 10 × 10 × 1.73 in (25.4 × 25.4 × 4.39 cm)
Weight ~3 kg
Warranty Limited Lifetime
