UniFi Switch Aggregation - High-Performance 10G Fiber Networking Solution
The Ubiquiti USW-Aggregation is a fully managed Layer 2 aggregation switch designed to deliver high-performance 10G fiber networking in a compact, fanless form factor. Featuring eight 10G SFP+ ports, it supports high-bandwidth uplinks, link aggregation, and seamless integration with UniFi's scalable management ecosystem.
Features :
This high-performance aggregation switch features 8x 10G SFP+ ports for ultra-fast fiber uplinks, making it ideal for high-bandwidth network connections. As a Layer 2 switch, it supports VLANs, link aggregation, and port monitoring for flexible network configuration. The fanless, silent operation makes it perfect for noise-sensitive environments, while its compact 1U rackmount form factor with only 4.7" depth allows for installation in space-constrained areas. Fully manageable via the UniFi Controller, it enables simple configuration, monitoring, and troubleshooting from a centralized interface.
Advanced Options :
The USW-Aggregation is designed for seamless integration with UniFi's scalable management ecosystem, providing administrators with powerful tools for network management. The switch supports advanced Layer 2 features including VLAN segmentation, link aggregation for increased bandwidth and redundancy, and detailed port monitoring for network optimization. Its modular design with 8 SFP+ slots allows for flexible network expansion as needs grow. With a maximum power consumption of just 30W and passive cooling, it offers energy-efficient operation without compromising performance. This makes it an ideal choice for fiber aggregation, high-throughput access, or enterprise distribution layers in both small-to-medium businesses and larger enterprise deployments.
Product Key Features
- 8x 10G SFP+ ports for ultra-fast fiber uplinks
- Layer 2 switching with support for VLANs, link aggregation, and port monitoring
- Fanless, silent operation for noise-sensitive environments
- Compact 1U rackmount form factor with only 4.7" depth
- Fully managed via UniFi Controller for seamless integration and control
- Ideal for fiber aggregation, high-throughput access, or enterprise distribution layers
Reliability & Performance :
The USW-Aggregation delivers exceptional reliability and performance in a compact form factor. Its fanless design eliminates potential mechanical failure points while ensuring silent operation in noise-sensitive environments. The switch's passive cooling system efficiently dissipates heat without fans, maintaining optimal operating temperatures even under continuous load. With a wide operating temperature range of 0°C to 40°C (32°F to 104°F), it can reliably function in various environmental conditions. The internal power supply provides stable power delivery with minimal energy consumption (max 30W), making it both cost-effective and environmentally friendly. Whether deployed as an aggregation point in a larger network or as a core switch in smaller installations, the USW-Aggregation provides consistent, high-performance 10G connectivity with minimal maintenance requirements.
