Designed for high availability, the XSM4328FV supports non-stop forwarding (NSF) virtual chassis stacking, allowing up to eight units to be managed as a single logical entity with hitless failover across the stack. Its half-width form factor allows for efficient side-by-side mounting in a standard 1U rack space, making it an ideal choice for space-constrained data centers or AV racks. For IT administrators, the switch offers a comprehensive Layer 3 feature set, including OSPF, static routing, and PIM, manageable via a feature-rich CLI or a streamlined web interface without the burden of recurring licensing fees.
Key Features
- 24x 10G SFP+ ports with 4x 10G combo copper/fiber ports.
- Pre-configured IGMP Plus for seamless AV-over-IP setup.
- Mixed stacking with any M4300 model for high resiliency.
- Full Layer 3 feature set including OSPF, VRRP, and PIM.
Specifications
| Brand | Netgear |
| Part Number | XSM4328FV-100NES |
| Product Type | Managed Stackable Switch |
| Switching Capacity | 560 Gbps |
| Throughput | 416.6 Mpps |
| Port Configuration | 24x 10G SFP+, 4x 10GBASE-T/SFP+ Combo |
| Form Factor | Rackmount (Half-width) |
| Power Supply | 1x Modular APS250W (Supports 1+1 Redundancy) |
| Latency | < 1.15 µs (10G SFP+ to 10G SFP+) |
| MAC Address Table | 32,000 entries |
| VLAN Support | Up to 4,000 concurrent VLANs |
| Operating Temperature | 0° to 50° C |
| Dimensions | 212 x 44 x 345 mm |
Frequently Asked Questions
Does this switch support redundant power supplies?
Yes, the XSM4328FV features a modular power supply bay. It ships with one APS250W unit, and a second can be added for 1+1 redundancy to ensure continuous operation in the event of a PSU failure.
Is this switch suitable for SDVoE and AV-over-IP deployments?
Absolutely. The M4300 series is specifically designed for AV-over-IP. It includes IGMP Plus, which automates multicast settings across the stack for zero-touch configuration of AV endpoints.
Can I stack this switch with other Netgear M4300 models?
The XSM4328FV can be stacked with any other Netgear M4300 series switch, regardless of port count or media type (1G or 10G), using standard 10G ports for the stacking link.
