HPE S0U73A ANW 5420 20G CL4 4P TAA MODULE View larger

HPE S0U73A Aruba CX 5420 20 Port 1G Switch Chassis

New

HPE S0U73A ANW 5420 20G CL4 4P TAA MODULE
×




  • New

Detailed Specifications

HPE S0U73A – Aruba CX 5420 20-Port 1G Class-4 PoE + 4 SFP+ Module

Overview

The HPE S0U73A is a mixed-port line card for the Aruba CX 5420 modular chassis. It delivers 20 copper ports of 10/100/1000 with PoE Class 4, plus four SFP+ uplink ports that support 1 Gb or 10 Gb. This module is ideal when you need to power devices (like phones, APs, IoT) at the edge, while maintaining high-bandwidth uplinks via SFP+. In a practical deployment, it could handle dozens of PoE-powered access points or cameras while tying back to the core or aggregation layer through its SFP+ ports. It’s built to run under AOS-CX, so you retain full Layer-3 routing and modern network automation features. The card is TAA-compliant, making it suitable for enterprise or regulated procurement, and fits into the CX 5420’s 4U, 6-slot chassis.

Key Features

  • 20× 1 Gb RJ-45 ports with Class 4 PoE, powering a broad array of edge devices.

  • 4× SFP+ uplinks (1G/10G) for high-speed connectivity to aggregation or core switches.

  • Generous PoE budget (~600 W) to support multiple high-draw PoE devices.

  • Layer-3 functionality via AOS-CX, enabling OSPF, static routing, VRRP, and ACLs.

Technical Specifications

SpecificationDetail
Brand HPE / Aruba Networking
Part Number S0U73A
Product Type Modular Switch Line Card (Chassis Plug-in)
Port Configuration 20 × 10/100/1000 RJ-45 + 4 × SFP+ (1G/10G)
PoE Class Class 4 (802.3at / 802.3bt)
PoE Power Budget ~600 W (for all powered ports)
Switching Capacity (per Module) ~60 Gbps (per official line-card spec)
Management / OS Managed by AOS-CX (CLI, SNMP, Web)
Power Requirements Powered from the CX 5420 chassis power system
Cooling Front-to-back airflow via chassis design
Operating Temperature 0 °C to 45 °C
