Detailed Specifications
Ubiquiti UACC-ETH-SP-PRO Ethernet Surge Protector
Overview
The Ubiquiti UACC-ETH-SP-PRO is an outdoor Ethernet surge protector designed to safeguard network equipment from lightning strikes, electrostatic discharge, and transient voltage surges. It supports high-speed data links and PoE passthrough while diverting harmful surge energy safely to ground. The device is built for deployment with outdoor access points, cameras, and bridge radios. Its compact, weather-resistant enclosure enables reliable protection in exposed environments.
Key Features
20kA surge discharge protection
Supports 10GbE data line speeds
PoE passthrough for powered devices
IPX5 weather-resistant enclosure
Technical Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number | UACC-ETH-SP-PRO |
| Product Type | Ethernet surge protector |
| Networking Interface | (2) RJ45 female ports |
| Data Line Protection | Up to 10 Gbps |
| Maximum Discharge Current | 20 kA |
| DC Spark-Over Voltage | 90 V @ 100 V/s |
| Max Impuse Spark-Over Voltage | 600 V @ 1 kV/µs |
| PoE Support | Yes (pass-through) |
| Enclosure Material | Polycarbonate |
| Ingress Protection | IPX5 |
| Operating Temperature | -30°C to 65°C |
| Dimensions | 91 × 61 × 32.5 mm |
| Weight | 95 g |
