Ubiquiti Networks ETH-SP-G2 Ethernet Surge Protector Gen 2 View larger

Ubiquiti Networks ETH-SP-G2 Ethernet Surge Protector Gen 2

ETH-SP-G2

New

In Stock

Ubiquiti Networks ETH-SP-G2 Ethernet Surge Protector Gen 2
×




dc supplies, Ethernet Surge Protector, Ubiquiti UniFi System, ETH-SP-G2, Ubiquiti ETH-SP-G2, ETH-SP-G2 Surge Protector, Ubiquiti Surge Protector, Ubiquiti Networks Surge Protecto, Ubiquiti Surge Protector, Network Equipment Protection

$12.99

Detailed Specifications

Ubiquiti Networks ETH-SP-G2 Ethernet Surge Protector Gen 2

Overview :

The 2nd generation Ubiquiti Networks Ethernet Surge Protector safeguards your outdoor non-PoE and PoE-based systems from voltage threats such as surges and electrostatic discharge events, which can render an entire network system inoperable. This protector is suitable for use with surveillance cameras, access points, and other Ethernet-equipped devices. Ubiquiti Networks has designed it with two surge-protected Ethernet ports that support Gigabit connection speeds. Furthermore, an external housing guards the Ethernet ports along with the surge protector from outdoor elements.

Specifications :

Interfaces
2 x RJ45 Female connectors
ESD/EMP Protection
Absorbing transient current with response to surge voltage from 100 V/s to 1 kV/µs
Power
DC Spark-Over Voltage
90 V @ 100 V/s
Maximum Impulse Spark-Over Voltage
700 V @ 1 kV/µs
Discharge Current
10 kA+
Insulation
Maximum Insulation Resistance
1 G ohm @ 50 V
Capacitance
1.0 pF @ 1 MHz (max.)
Data Line Protection
RJ45 10/100/1000 Ethernet
PoE Support
802.3af PoE support
Shock and Vibration
ETSI300-019-1.4 standard
Temperature & Humidity
Operating Temperature
-22 to 149°F / -30 to 65°C
Operating Humidity
10 to 90% non-condensing
Dimensions
3.58 x 2.40 x 1.28" / 91.0 x 61.0 x 32.5 mm
Weight
2.82 oz / 80 g
Packaging Info
Package Weight
0.235 lb
Box Dimensions (LxWxH)
3.7 x 2.45 x 1.3"
