Detailed Specifications
Eaton SPS610HGRA - 6-Outlet Hospital-Grade Surge Protector 120V
Overview
The Eaton SPS610HGRA is a hospital-grade surge protector power strip designed for controlled power distribution in healthcare and administrative environments. It is deployed by facility engineers, biomedical teams, and IT staff where UL-compliant hospital-grade connectivity is required for non-critical equipment. The unit addresses the need for safe, relocatable power distribution with surge suppression in environments subject to strict electrical compliance standards.
The device operates on a 120 V AC single-phase system and provides six NEMA 5-15R hospital-grade outlets, supported by a 15 A circuit breaker and 1050-joule surge protection rating. It is designed to protect connected equipment from voltage spikes and transient surges while maintaining consistent power delivery for low-to-moderate load devices.
Physically, the SPS610HGRA is a horizontal strip-style unit with a compact metal enclosure suitable for placement on desks, carts, or wall-mounted surfaces. It includes keyhole mounting slots and a 10-ft (3.05 m) cord with a right-angle hospital-grade plug, enabling installation in tight or space-constrained environments such as medical carts or workstation clusters.
Integration into facility power infrastructure is straightforward, using standard NEMA 5-15P-HG input connections compatible with hospital-grade receptacles. The unit includes a diagnostic LED indicator for line power presence and a locking switch cover to prevent accidental shutdown. It complies with UL 1363 and UL 1449 standards, meeting regulatory requirements for healthcare administrative areas.
A practical deployment includes powering workstations, monitors, or mobile medical carts in administrative or non-patient-care zones where surge protection and compliance are required. This unit is not suitable for patient-care vicinities, as it is explicitly designed for use outside critical care environments, and should not be used for life-support or diagnostic equipment requiring isolated or medical-grade power systems.
Key Features
- 6 NEMA 5-15R hospital-grade outlets for secure connections
- 1050-joule surge suppression for transient voltage protection
- 10-ft cord with right-angle hospital-grade NEMA 5-15P plug
- All-metal housing for durability in healthcare environments
- Locking switch cover prevents accidental power interruption
Specifications
| Specification | Detail |
|---|
| Brand | Eaton (Tripp Lite) |
| Part Number | SPS610HGRA |
| Product Type | Hospital-Grade Surge Protector |
| Input Voltage | 120 V AC |
| Frequency | 50/60 Hz |
| Maximum Current | 15 A |
| Power Capacity | 1800 W / 1800 VA |
| Surge Protection | 1050 joules |
| Maximum Surge Current | 19,500 A |
| Response Time | < 1 ns |
| Input Plug | NEMA 5-15P-HG (right-angle) |
| Output Receptacles | 6 × NEMA 5-15R-HG |
| Cord Length | 10 ft (3.05 m) |
| Circuit Protection | 15 A breaker |
| Housing Material | Metal |
| Mounting | Keyhole slots / surface mount |
| Indicators | Line power LED |
| Dimensions (W×D×H) | 13.75″ × 2.5″ × 1.5″ |
| Weight | ~2.55 lb |
| Certifications | UL 1363, UL 1449, cUL, RoHS |
