Overview
The Ubiquiti UISP-Connector-GND is a shielded RJ45 connector with an integrated grounding wire, designed for use with UISP Ethernet cables including UISP Cable Pro and Cable Carrier. The connector provides a grounding path intended to help protect connected Ethernet hardware from electrostatic discharge.
Grounding Design
Each connector includes a 1 m grounding wire that can be connected to a tower grounding system or metal mounting bracket. The grounding connection is integrated into the connector assembly, allowing installation without soldering.
Connector Construction
The UISP-Connector-GND is an RJ45 male connector with shielding and a dedicated grounding wire. It uses 22 AWG copper cable with a black PVC jacket.
UISP Cable Compatibility
Ubiquiti designed the UISP-Connector-GND for UISP Ethernet cables, specifically UISP Cable Pro and Cable Carrier. It is intended for installations where the Ethernet cable shielding and grounding need to be incorporated into the connector termination.
Key Features
- Shielded RJ45 male connector with grounding wire
- Integrated 1 m grounding wire
- Designed for UISP Cable Pro and Cable Carrier
- Supports grounding to a tower grounding system or metal mounting bracket
- 20 connectors supplied per pack
Applications
The UISP-Connector-GND is intended for UISP outdoor Ethernet installations where shielded cable termination and grounding are required. The integrated grounding lead provides a connection point for an appropriate tower grounding system or metal mounting bracket.
DC Supplies Product Note
The UISP-Connector-GND is supplied as a 20-pack of shielded RJ45 connectors with integrated grounding wires. Ubiquiti specifies it for UISP Cable Pro and Cable Carrier, so the cable type should be confirmed before installation.
Specifications
| Brand | Ubiquiti |
|---|
| Part Number / MPN | UISP-Connector-GND |
|---|
| Product Type | Surge Protection Connector GND |
|---|
| Connector Type | RJ45 male |
|---|
| Connector Shielding | Shielded |
|---|
| Grounding Wire | Integrated |
|---|
| Grounding Wire Length | 1 m (3.3 ft) |
|---|
| Wire Gauge | 22 AWG |
|---|
| Wire Material | Copper |
|---|
| Jacket Material | Black PVC |
|---|
| Compatible Cables | UISP Cable Pro, UISP Cable Carrier |
|---|
| Grounding Connection | Tower grounding system or metal mounting bracket |
|---|
| Installation | No soldering required |
|---|
| Pack Type | 20-pack |
|---|
FAQs
What is the UISP-Connector-GND used for?
It is a shielded RJ45 connector with an integrated grounding wire for terminating compatible UISP Ethernet cables.
Which UISP cables are compatible?
Ubiquiti specifies the connector for UISP Cable Pro and UISP Cable Carrier.
How long is the integrated grounding wire?
The integrated grounding wire is 1 m (3.3 ft) long.
Where should the grounding wire be connected?
Ubiquiti specifies connection to a tower grounding system or metal mounting bracket.
How many connectors are included?
The UISP-Connector-GND is supplied as a 20-pack.
