APC SRT5KRMTF Smart-UPS 5KVA 2U RM Step Down Transformer

New

In Stock

5 kVA rack-mount step-down transformer
×




$872.00

  • New

Detailed Specifications

APC SRT5KRMTF – 5 kVA Step-Down Transformer

Overview :

The APC SRT5KRMTF is a 5 kVA rack-mount transformer used in IT power systems to convert 208 V input to 120 V outputs. It is intended for engineers installing Smart-UPS systems to provide proper voltage for downstream rack equipment. It fits in 2U rack space and supplies multiple NEMA 5-20R outlets for branch circuits. This transformer is often installed upstream of UPS gear to limit inrush and saturation stress on the UPS.

Key Features :

  • Step-down from 208 V to 120 V for mixed-voltage racks

  • Twelve NEMA 5-20R output receptacles

  • Rack-mount 2U form factor (mounts in 19" rack)

  • 30 A input via NEMA L6-30P plug

Specifications :

ParameterValue
Brand APC by Schneider Electric
Part Number SRT5KRMTF
Product Type Step-down Transformer (rack model)
Power Rating 5000 VA
Nominal Input Voltage 208 V
Input Receptacle Type NEMA L6-30P
Nominal Output Voltage 120 V
Output Receptacle Type / Count 12 × NEMA 5-20R
Maximum Input Current 30 A
Dimensions (H × W × D) 3.5" × 17.01" × 25.08" (89 mm × 432 mm × 637 mm)
Rack Height 2U
Net Weight 95 lb (≈ 43.09 kg)
Operating Temperature Range 0 °C to 40 °C
Warranty 2 years (repair or replace)
