APC AP9626 Step-Down Transformer 2U Rack-Mount 208V to 120V View larger
Previous Next

APC AP9626 Step-Down Transformer RM 2U 208V to 120V w/ 5-20R

New

In Stock

Efficient step-down transformer converting 208V to 120V for low-voltage equipment
×




$819.90

  • New

Detailed Specifications

APC

AP9626

Step‑Down Transformer – RM 2U, 208 V to 120 V w/ (12) 5‑20R

The APC AP9626 Step‑Down Transformer is a rugged, rack-mountable 2 U unit that converts high-voltage power to standard 120 V outlets. Perfect for environments where equipment needs U.S.–style receptacles but only higher voltages are available, making it ideal in data centers, labs, and industrial racks.

Features

The AP9626 transformer seamlessly integrates into 19-inch rack systems, converting 208 V power into usable 120 V through twelve NEMA 5‑20R outlets—ideal for powering racks full of servers, monitors, and peripherals. With a 5 kVA capacity and built-in circuit breaker, it ensures safe and efficient power distribution

Advanced Options

Designed with 90 % efficiency, the AP9626 reduces thermal output—beneficial in high-density environments. It ships with all necessary mounting brackets and a detailed user manual to enable rapid, professional installations into IT and industrial rack systems .

Product Key Features

  •  Converts 208 V (or 200 V) input to 120 V output in compact 2 U rack form

  •  Provides 12 NEMA 5‑20R outlets for standard AC equipment

  •  Supports 5 kVA (5000 VA) output capacity with 24 A max draw

  •  Includes rack-mount brackets and installation manual

  •  90 % efficiency to minimize heat and energy loss

  •  Built-in circuit breaker for overload protection

Reliability & Performance

Constructed for continuous mission-critical use, the 2 U AP9626 provides stable 120 V output with minimal heat generation thanks to its high efficiency. The internal circuit breaker safeguards against overloads, and certified compliance (UL 1778, CSA) guarantees dependable operation. It is supported by APC’s 2-year repair or replace warranty, offering trustworthy performance in demanding environments .

Key Features (Bullet List)

  • Step-down from 208 V to 120 V

  • Rack-mountable 2 U form factor

  • 5 kVA load capacity

  • Twelve NEMA 5‑20R output receptacles

  • NEMA L6‑30P input connector

  • 24 A max input / 24 A max output

  • Integrated circuit breaker

  • 90 % energy efficiency

  • Includes rack-mount brackets and manual

  • UL 1778 and CSA compliant

Specifications :

SpecificationDetails
Model Number AP9626
Product Type Step-Down Transformer
Rack Mounting Height 2 U
Input Voltage 208 V (works with 200 V)
Input Connector NEMA L6‑30P
Output Voltage 120 V
Output Receptacles 12 × NEMA 5‑20R
Load Capacity 5000 VA
Max Input Current 24 A
Max Output Current 24 A
Efficiency 90 %
Circuit Protection Built-in circuit breaker
Dimensions (H × W × D) 3.5″ × 17.5″ × 24.0″ (89 × 445 × 610 mm)
Weight 95.2 lb (43.2 kg)
Certifications UL 1778, CSA
Warranty 2-Year Repair or Replace
