Detailed Specifications
Samsung MZ-VAP2T0B/AM PM9A1 2TB M.2 2280 PCIe Gen4 x4 NVMe Solid State Drive
Overview
The Samsung MZ-VAP2T0B/AM, part of the PM9A1 series, is an enterprise-grade PCIe Gen4 x4 NVMe Solid State Drive engineered for high-performance computing and data-intensive environments. Utilizing Samsung's advanced V-NAND technology and an in-house controller, this drive delivers significant bandwidth improvements over Gen3 counterparts, making it an ideal solution for workstations, high-end PCs, and server boot drives where low latency and high IOPS are critical.
Infrastructure teams and IT procurement specialists deploy the PM9A1 to handle complex workloads such as 3D rendering, data analytics, and large-scale software development. The drive supports the NVMe 1.4 protocol, optimizing command queues for enhanced efficiency. With its M.2 2280 form factor, it provides a compact, cable-less storage expansion that integrates seamlessly into modern motherboard architectures and dense server chassis.
5. Key Features
PCIe Gen4 x4 Interface: Doubles the sequential data transfer rates over Gen3.
Advanced Samsung V-NAND: High-density storage with enhanced endurance and reliability.
NVMe 1.4 Protocol: Optimized efficiency for high-speed enterprise workloads.
In-House Samsung Controller: Ensures thermal stability and consistent performance.
M.2 2280 Form Factor: Standardized compact design for universal system compatibility.
6. Technical Specifications
| Specification | Details |
| Brand | Samsung |
| Part Number | MZ-VAP2T0B/AM |
| Product Type | NVMe M.2 SSD |
| Capacity | 2 TB |
| Interface | PCIe Gen4 x4 |
| Protocol | NVMe 1.4 |
| Form Factor | M.2 (2280) |
| Sequential Read | Up to 7,000 MB/s |
| Sequential Write | Up to 5,200 MB/s |
| Random Read (4KB) | Up to 1,000,000 IOPS |
| Random Write (4KB) | Up to 850,000 IOPS |
| Dimensions (LxWxH) | 3.15 x 0.87 x 0.09 Inches |
| Product Weight | 0.02 Lbs |
| MTBF | 1,500,000 Hours |
