Detailed Specifications
APC SMT1500RM2UC Smart-UPS 1500VA 1000W 120V Rackmount 2U UPS, Line-Interactive, Pure Sine Wave
LONG DESCRIPTION
The APC SMT1500RM2UC Smart-UPS is a 1440VA/1000W line-interactive uninterruptible power supply designed for servers, storage systems, network equipment, business VoIP, retail POS, and other critical IT applications.
This exact SMT1500RM2UC model is a 2U rackmount UPS designed for 120V environments. It provides six NEMA 5-15R output outlets and uses a NEMA 5-15P input connection with an 8-foot power cable. The UPS delivers pure sine wave output and includes Automatic Voltage Regulation (AVR) to help correct utility-voltage fluctuations.
SmartConnect Ethernet connectivity provides cloud-based remote UPS monitoring, while SmartSlot, USB, and serial interfaces support additional management capabilities and graceful shutdown with compatible software. An LCD provides local UPS status and configuration information.
The SMT1500RM2UC uses a maintenance-free sealed lead-acid battery and supports the APC APCRBC159 replacement battery cartridge. Rack mounting support rails and a USB cable are included.
OVERVIEW
The APC SMT1500RM2UC is a 1440VA/1000W line-interactive 120V 2U rackmount UPS with pure sine wave output, AVR, six NEMA 5-15R outlets, SmartConnect, SmartSlot, and LCD monitoring.
KEY FEATURES
- Exact APC model: SMT1500RM2UC
- 1440VA / 1000W rated capacity
- Line-interactive UPS topology with pure sine wave output
- Automatic Voltage Regulation (AVR)
- Six NEMA 5-15R battery-backup and surge-protected outlets
- SmartConnect Ethernet port for cloud-based remote monitoring
- SmartSlot expansion interface
- USB and serial communication interfaces
- LCD display for local UPS status and configuration
- 2U rackmount design with support rails included
SPECIFICATIONS
| SpecificationValue | |
|---|
| Brand | APC |
| Manufacturer | Schneider Electric |
| MPN | SMT1500RM2UC |
| Product Type | Uninterruptible Power Supply (UPS) |
| Model | SMT1500RM2UC |
| Product Family | Smart-UPS |
| UPS Technology | Line-interactive |
| Form Factor | Rackmount |
| Rack Height | 2U |
| Rated Capacity | 1440 VA |
| Rated Power | 1000 W |
| Input Voltage | 120 V AC |
| Other Input Voltages | 110 V / 125 V |
| Output Voltage | 120 V AC |
| Other Output Voltages | 110 V / 125 V |
| Input Connection | NEMA 5-15P |
| Output Connections | 6 × NEMA 5-15R |
| Output Waveform | Pure sine wave |
| Automatic Voltage Regulation | Yes |
| Communication Interfaces | SmartConnect Ethernet, USB, Serial |
| Expansion Interface | SmartSlot |
| Display | LCD |
| Battery Type | Sealed Lead-Acid / VRLA |
| Replacement Battery | APC APCRBC159 |
| Typical Recharge Time | 3 hours |
| Power Cord Length | 8 ft |
| Product Dimensions | 3.39 × 17.01 × 18.78 in (H × W × D) |
| Product Weight | 58.42 lb |
| Shipping Dimensions | 9.25 × 23.23 × 24.02 in (H × W × D) |
| Shipping Weight | 70.81 lb |
| Operating Temperature | 32-104°F |
| Operating Humidity | 0-95% relative humidity |
| Warranty | 3 years UPS; 2 years battery |
