APC SMT2200RMI2U - 2.2 kVA Rackmount UPS
Overview :
The APC SMT2200RMI2U is a 2.2 kVA (1980 W) line-interactive UPS designed to provide regulated AC power and battery backup for rack-mounted servers, storage systems, and networking equipment. It is deployed by IT engineers, network architects, and infrastructure managers in IDF/MDF racks, server rooms, and branch offices where stable power and short-duration backup are required.
This UPS uses line-interactive topology with Automatic Voltage Regulation (AVR) to correct under- and over-voltages without unnecessary battery use, preserving battery life and maintaining consistent output. It delivers pure sine-wave output at 120 V, compatible with sensitive electronics and active-PFC devices.
The unit comes in a 2U rackmount chassis for standard 19-inch server racks. An LCD control panel provides real-time information on load, battery status, and event conditions, simplifying monitoring and diagnostics. Batteries are hot-swappable, allowing replacement without disrupting protected loads.
Management interfaces include USB and serial ports, enabling remote monitoring, event logging, and controlled shutdown via compatible software. Audible alarms notify operators of battery status and power events.
In deployment, this UPS is suitable for medium server racks, network switches, and storage arrays. It should not be used for systems that require full double-conversion online UPS protection with zero transfer time.
Key Features
• 2.2 kVA / 1980 W line-interactive UPS with AVR
• 2U rackmount chassis with LCD status panel
• Pure sine-wave output for sensitive IT equipment
• 6 IEC C13 outlets plus 2 IEC jumper outputs
• Hot-swappable sealed lead-acid battery
Specifications :
| Specifications | Detail |
|---|
| Brand | APC |
| Part Number | SMT2200RMI2U |
| Product Type | Line-Interactive Rackmount UPS |
| Rated Capacity | 2200 VA / 1980 W |
| Topology | Line-interactive with AVR |
| Nominal Input Voltage | 120 V AC |
| Input Voltage Range | ~75-153 V AC |
| Nominal Output Voltage | 120 V AC |
| Output Waveform | Pure sine wave |
| Frequency | 50/60 Hz auto-sensing |
| Outlets | 6 × IEC-320 C13, 2 × IEC jumper outputs |
| Input Connector | NEMA 5-15P |
| Battery Type | Sealed lead-acid, hot-swappable |
| Typical Runtime | ~5 min @ full load; ~15 min @ half load |
| Recharge Time | ~3 hours |
| Transfer Time | ~2-4 ms |
| Dimensions (W×H×D) | 432 × 86 × 686 mm |
| Weight | ~39 kg |
