Ergotron 33-351-200 – WorkFit-S Single HD Sit-Stand Workstation with Worksurface
Overview
The Ergotron 33-351-200 WorkFit-S Single HD is a front-clamp sit-stand workstation designed for a single heavier monitor. It supports displays up to 30 inches with a monitor weight range of 16–28 lb and provides an 18-inch tandem adjustment range for the monitor and keyboard. The integrated 23 × 15-inch worksurface provides additional space for office equipment and accessories.
Technical Information
The height-adjustment assembly supports a maximum combined load of 29 lb, including the monitor, keyboard tray and worksurface. The monitor provides 4.8 inches of independent height adjustment in addition to the 18-inch tandem movement, giving a maximum monitor height adjustment of 22.8 inches. The monitor supports 30° of tilt and 90° portrait-to-landscape rotation.
Compatibility
The 33-351-200 is designed for single displays up to 30 inches using VESA-compatible mounting. The monitor pivot supports displays weighing 16–28 lb, while the worksurface and keyboard tray each have a maximum 5 lb load within the 29 lb total system limit. The desk clamp attaches to worksurfaces approximately 0.47–2.4 inches thick.
Key Features
- Supports one monitor up to 30 inches.
- Handles 16–28 lb monitor loads within a 29 lb total system capacity.
- Provides 18 inches of tandem monitor and keyboard adjustment.
- Includes an integrated 23 × 15-inch worksurface and 27 × 9-inch keyboard tray.
- Supports 30° monitor tilt and 90° portrait-to-landscape rotation.
Applications
The WorkFit-S Single HD is suited to office workstations, professional work areas, shared desks and ergonomic desktop deployments where a heavier single monitor requires sit-stand adjustment without replacing the existing desk.
DC Supplies Product Note
This listing is specifically for Ergotron MPN 33-351-200, the black WorkFit-S Single HD configuration with worksurface. It should not be substituted with the lighter 33-350-200 Single LD or the dual-monitor 33-349-200 configuration, as their monitor capacities and mounting configurations differ.
Specifications
| Brand | Ergotron |
|---|
| MPN | 33-351-200 |
|---|
| Product Type | Sit-Stand Workstation |
|---|
| Series | WorkFit-S |
|---|
| Configuration | Single HD Monitor with Worksurface |
|---|
| Color | Black |
|---|
| Display Capacity | 1 monitor |
|---|
| Typical Maximum Display Size | 30 inches |
|---|
| Monitor Weight Range | 16–28 lb (7.3–12.7 kg) |
|---|
| Maximum Total Load | 29 lb (13.2 kg) |
|---|
| Tandem Height Adjustment | 18 inches (46 cm) |
|---|
| Independent Monitor Adjustment | 4.8 inches (12.2 cm) |
|---|
| Maximum Monitor Height Adjustment | 22.8 inches (58 cm) |
|---|
| Monitor Tilt | 30° |
|---|
| Monitor Rotation | 90° |
|---|
| VESA Compatibility | MIS-D/E/F |
|---|
| Worksurface Dimensions | 23 × 15 inches |
|---|
| Worksurface Maximum Load | 5 lb (2.3 kg) |
|---|
| Keyboard Tray Dimensions | 27 × 9 inches |
|---|
| Keyboard Tray Maximum Load | 5 lb (2.3 kg) |
|---|
| Desk Clamp Range | 0.47–2.4 inches (1.2–6 cm) |
|---|
| Shipping Dimensions | 8 × 23 × 44 inches |
|---|
| Shipping Weight | 44 lb (20 kg) |
|---|
| Warranty | 5 years |
|---|
Specifications are based on exact-model Ergotron documentation and supporting distributor data.
FAQs
What monitor size does the Ergotron 33-351-200 support?
The WorkFit-S Single HD supports a typical maximum display size of 30 inches.
What is the monitor weight capacity?
The monitor pivot is designed for displays weighing 16–28 lb (7.3–12.7 kg), while the complete height-adjustment assembly has a 29 lb maximum total load.
How much height adjustment is available?
The monitor and keyboard move together through an 18-inch range, with an additional 4.8 inches of independent monitor adjustment and a maximum monitor height adjustment of 22.8 inches.
Does it include a worksurface?
Yes. The exact 33-351-200 configuration includes a 23 × 15-inch worksurface and a large 27 × 9-inch keyboard tray.
What desk thickness can the clamp accommodate?
The front desk clamp attaches to desk surfaces approximately 0.47–2.4 inches (1.2–6 cm) thick.
What VESA mounting standard is supported?
The exact-model documentation identifies VESA MIS-D/E/F compatibility. Larger mounting patterns can be accommodated using the separately available Ergotron VESA Bracket Adaptor Kit where applicable.
Verification
Verification status: VERIFIED — exact MPN 33-351-200. The model, configuration, display capacity, load limits, adjustment range, worksurface dimensions, mounting specifications and warranty were cross-checked against Ergotron documentation and exact-MPN distributor data.
