Detailed Specifications
HP JD098B - 1 Gb SFP LC BX 10-U Transceiver
Overview :
The HP JD098B is a 1 Gb Small Form-Factor Pluggable (SFP) optical transceiver used by network engineers to link switches or media converters over a single-mode fibre span. It supports 1000Base-BX10-U operation, providing a transmit wavelength of 1310 nm and receive wavelength of 1490 nm, with a reach of up to 10 km over single-mode fibre. This module is suited for deployment in data-centre aggregation, campus fibre runs or edge-access links where duplex fibre is scarce and bidirectional transmission is required. It integrates into HP networking platforms (including the X120 series) and supports digital diagnostics (DOM) for live fibre-link monitoring.
Key Features :
Operates at 1310 nm TX / 1490 nm RX wavelengths
Single-mode fibre support up to 10 km reach
LC simplex connector in SFP form-factor
Power consumption below 1.0 W (typical ~0.8 W)
Digital optical monitoring interface (DOM) enabled
Specifications :
| Specification | Value |
|---|
| Brand | HP |
| Part Number | JD098B |
| Product Type | 1 Gb SFP LC BX 10-U Transceiver |
| Data Rate | 1.25 Gb/s maximum |
| Wavelength (Tx) | 1310 nm |
| Wavelength (Rx) | 1490 nm |
| Maximum Distance | 10 km |
| Fibre Type | Single-mode fibre (SMF) |
| Connector | LC simplex |
| Power Consumption (typ) | 0.8 W |
| Operating Temperature | 0 °C to +70 °C |
| Dimensions (L×W×H) | 2.17 in × 0.60 in × 0.46 in |
| Weight | 0.04 lb (≈0.02 kg) |
| DOM/Diagnostics | Supported |
| Compliance Standards | IEEE 802.3z, SFP MSA, RoHS |
