Detailed Specifications
Xerox 097N02452 - EX-i PrimeLink C9000 Print Server
Overview :
Xerox 097N02452 is an external print front-end controller powered by EFI Fiery (E500 series platform) designed specifically for commercial print operators, corporate marketing departments, and high-volume print production environments. It resolves performance bottlenecks associated with processing complex vector graphics, large variable data printing (VDP) runs, and high-resolution PDF files. By offloading heavy document rasterization directly from the engine to this dedicated, high-performance external processor, print environments can maintain maximum engine speed and throughput.
Technically, the print server is powered by an Intel Core i3-8100 processor running at 3.60 GHz, equipped with 4 GB of RAM and a dedicated 500 GB SATA hard disk drive for job spooling and caching. Built on a reliable Linux operating software platform, this controller features four high-speed USB 3.0 ports for fast local media inputs and direct server administration. The hardware leverages custom-designed file-compression algorithms to accelerate processing times and optimize system memory efficiency.
This front-end device is designed for space-efficient direct attachment deployment, mounting onto the rear of the device or sitting adjacent to the print engine within a corporate office, print center, or central production hub. It is strictly compatible with the Xerox PrimeLink C9065 and C9070 color multifunction printers. It should not be used as a standalone network server for unsupported printer lines or in low-volume standard office environments where a basic embedded controller is sufficient.
Key Features :
Intel Core i3 processor speeds up Raster Image Processor (RIP) times.
Built-in Fiery Edge profiles ensure highly accurate corporate colors.
Dedicates a 500 GB hard drive to manage large variable data print runs.
Standard Fiery JDF connection integrates seamlessly into CRM workflows.
Robust Linux OS platform secures print queues against external threats.
Specifications :
| Attribute | Specification |
| Brand | Xerox |
| Part Number | 097N02452 |
| Product Type | Print Server |
| Software Platform | Fiery FS500 software |
| Processor | Intel Core i3-8100 Processor |
| System Memory | 4 GB RAM |
| Hard Drive | 500 GB HDD |
| Operating System | Linux |
| Interface Ports | 4 x USB 3.0 |
| Target Printers | Xerox PrimeLink C9065 / C9070 |
| Document Formats | Adobe PostScript Level 1, 2, 3, Adobe PDF, Enhanced PCL 6 |
| Color Management | Fiery Spot-On, PANTONE Calibration |
