Detailed Specifications
ProLiant DL360 Gen10 1U Rack Server (1× Xeon Silver 4110, 16 GB RAM)
The HPE ProLiant DL360 Gen10 (874457-S01) is a robust 1U rack server that balances performance and efficiency. Equipped with a single Intel Xeon Silver 4110 CPU, 16 GB DDR4 memory, and Smart Array RAID, it's tailored for virtualization, cloud, and enterprise workloads in dense data center environments.
Features
Built on Intel's Scalable platform, the Xeon Silver 4110 delivers 8 cores/16 threads, offering Turbo speeds up to 3.0 GHz. The DL360 Gen10 includes eight hot-swappable 2.5″ drive bays and an integrated P408i-a RAID controller,
Advanced Options
perfect for high-performance data storage needs. Networking is handled through embedded quad 1 GbE plus flexible PCIe slots for 10 GbE or additional NICs. Integrated iLO 5 offers comprehensive remote administration×streamlining deployment and management.
Product Key Features
8-core Intel Xeon Silver 4110 @ 2.1 GHz (3.0 GHz Turbo)
16 GB DDR4-2666 MHz ECC RDIMM (1 of 12 slots, expandable up to 768 GB)
Smart Array P408i-a RAID with 2 GB FBWC
8 hot-swap SFF bays (SAS/SATA/SSD)
Embedded 4×1 GbE + flexible PCIe + iLO 5 remote management
500 W hot-plug power supply, supports optional redundant PSU
Reliability & Performance
Engineered for 24/7 operation, this server supports up to two Xeon CPUs and 768 GB of error-correcting memory. Thermal management is enhanced by multiple hot-plug fans, and power redundancy options include dual PSU support. Backed by energy-efficient design and robust RAS features (ASA, DDR4 ECC, etc.), it's ideal for continuous, mission-critical applications
Key Features (Bullet List)
Intel Xeon Silver 4110 (8-core, 2.1 GHz / 3.0 GHz Turbo)
16 GB DDR4-2666 ECC RDIMM (1×16 GB)
HPE Smart Array P408i-a RAID controller (2 GB FBWC)
8× hot-swap 2.5″ SFF drive bays (SAS/SATA/SSD)
Embedded 4×1 GbE LOM + PCIe expansion + iLO 5
500 W hot-plug PSU (supports optional redundant PSU)
| Specification | Details |
|---|
| Model Number | 874457-S01 |
| Chassis | HPE ProLiant DL360 Gen10, 1U rack server |
| Processor | Intel Xeon Silver 4110 (8 cores/16 threads) @ 2.1 GHz (3.0 GHz Turbo) |
| Max CPUs Supported | 2 sockets (Scalable family) |
| L3 Cache | 11 MB |
| Memory Installed | 16 GB DDR4-2666 ECC RDIMM (1×16 GB) |
| Max Memory Capacity | Up to 768 GB (12 DIMM slots) |
| Drive Bays | 8× 2.5″ hot-swap SFF (SAS/SATA/SSD) |
| RAID Controller | Smart Array P408i-a with 2 GB FBWC (RAID 0/1/5/6/10/50/60) |
| Networking | 4× 1 GbE LOM; PCIe 3.0 slots for expansion |
| Remote Management | iLO 5 integrated |
| Power Supply | 500 W hot-plug; optional redundant PSU support |
| Dimensions (H×W×D) | 1.7″ × 17.1″ × 27.8″ (4.32 cm × 43.4 cm × 70.6 cm) |
| Weight | ~28.75 lb (13 kg) |
| Warranty | 3-year parts and labour |
| Compliance | ASHRAE A3/A4, ENERGY STAR 2.1, FIPS 140-2, IPv6, PCI DSS, WEEE, RoHS |
