HPE ProLiant DL380 Gen9 Rack Server

New

HPE ProLiant DL380 Gen9: Rack-mountable, high-performance, highly expandable

×




  • New

Detailed Specifications

HPE 859085-S01

ProLiant DL380 Gen9 Rack Server–2× Xeon E5‑2690 v4,64 GB DDR4,8× SFF

The HPE ProLiant DL380 Gen9 859085‑S01 is a powerhouse 2U rack server built for mission-critical enterprise workloads. With dual 14-core Xeon CPUs and enterprise-grade memory and storage options, it’s ideal for virtualized environments, databases, and HPC tasks. Its modular design ensures flexibility and future expansion.

Features

This Gen9 server comes preconfigured with dual Intel Xeon E5‑2690 v4 processors and 64 GB DDR4 ECC memory, delivering high-throughput multi-threaded performance. The 8 SFF drive bays can support SAS or SATA HDD/SSD and can be field-upgraded to 24 SFF or 12 LFF bays.

Advanced Options

Managed storage is enabled via the P440ar RAID controller with battery backup, while redundant PSUs and hot-swap fans ensure high availability.iLO 4 simplifies remote management, firmware updates, and provisioning, making it well-suited for distributed data centers or mixed IT environments. Plus, its backplane offers optional FlexibleLOM and PCIe riser slots for networking or GPU add-ons

Product Key Features

    •  Dual Intel Xeon E5‑2690 v4 (14-core, 2.6 GHz each)

    •  64 GB DDR4 ECC memory (4×16 GB, up to 768 GB)

    •  8× SFF drive bays, expandable to 24 SFF or 12 LFF

    •  HPE Smart Array P440ar with 2 GB FBWC RAID controller

    •  Dual 800 W Flex Slot Platinum hot-plug power supplies

    •  iLO 4 remote management & redundant hot-swap fans

Reliability & Performance

Designed for durability, the DL380 Gen9 includes redundant power supplies, a minimum of four hot-plug fans (six on performance models), and Smart Socket Guide cooling The Flex Slot PSUs offer up to 96% efficiency. Embedded iLO ensures effective monitoring, alerting, and secure remote access—perfect for uptime-sensitive IT operations.

Key Features (Bullet List)

  • Dual Intel Xeon E5‑2690 v4 CPUs (14 cores @ 2.6 GHz)

  • 64 GB DDR4 ECC memory (4×16 GB; expandable to 768 GB)

  • 8x hot-plug SFF bays (expandable) with P440ar RAID

  • Dual 800 W platinum hot-plug power supplies

  • Embedded 4x1 GbE NIC; FlexibleLOM and PCIe expansion

  • HPE iLO 4 with Intelligent Provisioning

SpecificationDetails
Model Number 859085‑S01
Form Factor 2U rack-mountable
Processors 2× Intel Xeon E5‑2690 v4, 14-core, 2.6 GHz, 35 MB L3, 135 W
Memory 64 GB DDR4 Registered ECC (4×16 GB); 24 slots, up to 768 GB
Drive Bays 8× SFF hot-plug (support for SAS/SATA); expandable to 24× SFF or 12× LFF
Storage Controller HPE Smart Array P440ar/2 GB FBWC
RAID Levels 0/1/5/10
Network Interface Embedded 4×1 GbE; FlexibleLOM optional
Expansion Slots 6× PCIe Gen3 (3 standard, +3 with secondary riser)
Power Supplies 2× 800 W Flex Slot Platinum hot-plug (94–96% efficiency)
Fans 4–6 hot-plug, redundant (6 in performance config)
Management HPE iLO 4, Intelligent Provisioning, OneView compatible
Dimensions (H×W×D) 3.44 × 17.5 × 26.7 in (8.7 × 44.5 × 67.9 cm)
Weight (empty) ≈51.5 lb (23.6 kg)
