Detailed Specifications
HPE P20174-B21 - ProLiant DL380 Gen10 2U Rack Server (8 SFF)
Overview
The HPE P20174-B21 is a 2-rack-unit (2U) server model within the ProLiant DL380 Gen10 line that ships with one Intel Xeon Silver 4210 processor (10 cores at 2.2 GHz) and 32 GB of DDR4 memory installed into a chassis configured for 8 hot-plug small-form-factor (SFF) drive bays. It is intended for enterprise or branch-data-centre environments where you need a compact but capable server for general-purpose workloads × virtualization, application hosting, consolidation of services. It supports the Gen10 platform's manageability features such as HPE iLO and fits into HPE's ecosystem of storage, networking and services.
Key Features
Intel Xeon Silver 4210 (10 cores @ 2.2 GHz) provides solid multicore performance for mid-tier workloads.
8 front hot-plug SFF drive bays allow flexible storage (SAS/SATA) in a compact 2U format.
Ships with a 500 W Flex Slot power supply, enabling rack deployment with modest power budget and future expansion headroom.
Built-in enterprise-grade management (HPE iLO, Intelligent Provisioning) integrated in the DL380 Gen10 platform, making deployment, monitoring and support easier.
Technical Specifications
| Specification | Detail |
|---|
| Brand | HPE |
| Part Number | P20174-B21 |
| Product Type | Rack Server (2U) |
| Processor | 1 × Intel Xeon Silver 4210 (10 cores, 2.2 GHz) |
| Installed Memory | 32 GB DDR4 Registered |
| Drive Bays | 8 × SFF hot-plug front bays |
| Power Supply | 500 W Flex Slot Universal Hot Plug |
| Form Factor & Chassis | 2U rack mount |
| Management | HPE iLO Standard with Intelligent Provisioning (embedded) |
| Warranty | 3-year parts / 3-year labor / 3-year on-site typical |
