Detailed Specifications
HPE 867446-S01 ProLiant DL360 Gen9 1U Server
Overview
The HPE 867446-S01 is a 1 U rack-mount server aimed at IT infrastructure teams deploying dense compute nodes in enterprise data-centres or branch locations. It arrives with a single Intel Xeon E5-2640 v4 (10-core at 2.4 GHz) processor and 16 GB of DDR4 SmartMemory, offering a solid foundation for virtualization, application hosting and service-oriented workloads. With support for a second processor socket and up to 3 TB of DDR4 memory (via factory-supported configuration), it accommodates scaling as load increases. The chassis houses eight 2.5-inch small form-factor hot-plug drive bays managed by an HPE Smart Array P440ar controller, allowing SAS/SATA storage flexibility and enterprise RAID options. Built-in HPE iLO remote management enables systems monitoring, firmware control and lifecycle automation, making this model suitable for deployment in high-density racks, campus core nodes or converged compute/storage nodes.
Key Features
Single Intel Xeon E5-2640 v4 10-core processor at 2.4 GHz installed.
Eight hot-plug 2.5-inch SFF drive bays for SAS/SATA/SSD storage.
Smart Array P440ar controller with 12 Gb/s SAS and 2 GB FBWC cache.
Supports up to 24 DIMM slots and up to 3 TB of DDR4 SmartMemory.
Embedded 4-port 1 Gb Ethernet (331i) and HPE iLO remote hardware management.
Technical Specifications
| Specification | Detail |
|---|
| Brand | HPE |
| Part Number | 867446-S01 |
| Product Type | ProLiant DL360 Gen9 1U Rack Server |
| Processor Installed | Intel Xeon E5-2640 v4 (2.4 GHz, 10-core) |
| Processor Supported (Max) | Up to 2 × Intel Xeon E5-2600 v4 series |
| Memory Installed | 16 GB DDR4 SmartMemory |
| Memory Slots | 24 DIMM slots |
| Maximum Memory Supported | Up to 3 TB DDR4 |
| Drive Bays | 8 × 2.5-inch SFF hot-plug |
| Storage Controller | HPE Smart Array P440ar (12 Gb/s SAS, 2 GB FBWC) |
| Network Adapter | 4 × 1 Gb Ethernet (331i) |
| Form Factor (H × W × D) | 1.7 in × 17.1 in × 27.5 in |
| Weight (lbs) | ~33.0 lbs |
| Power Supply | 500 W Flex-Slot Platinum Hot-Plug |
| Rack Units | 1U |
