Detailed Specifications
HPE P71682-005 ProLiant DL20 Gen11 6-Core Server
Overview
The HPE P71682-005 is a compact 1U ProLiant DL20 Gen11 server, powered by a 6-core Intel Xeon E-2436 CPU, making it suited for branch, edge, or small-business deployments that require enterprise reliability in a dense, cost-effective form. It comes pre-installed with 32 GB of DDR5 memory and includes two 960 GB SATA SSDs for fast storage. The server supports four 2.5″ hot-plug bays, redundant power with dual 500 W Flex Slot supplies, and its management is handled through HPE iLO for real-time remote control and monitoring.
Key Features
Intel Xeon E-2436 (6 cores, 2.90 GHz)
32 GB DDR5 ECC memory installed
4 × 2.5″ SFF hot-plug drive bays
2 × 960 GB SATA SSDs included
MR408i-o Gen11 (storage controller)
Dual 500 W Flex Slot power supplies
iLO 6 for remote system management
1U rack form factor for space-efficiency
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE |
| Part Number | P71682-005 |
| Product Type | 1U Rack Server |
| Processor | Intel Xeon E-2436, 6 cores, 2.90 GHz |
| Memory Installed | 32 GB DDR5 |
| Memory Technology | DDR5 ECC |
| Maximum Memory Supported | 128 GB (per vendor spec) |
| Storage Bays | 4 × 2.5″ SFF hot-plug |
| Included Storage | 2 × 960 GB SATA SSD |
| Storage Controller | HPE MR408i-o Gen11 |
| Expansion Slots | PCIe Gen4 (slots and count depend on configuration) |
| Network | Built-in Gigabit network (OCP / embedded) |
| Power Supplies | 2 × 500 W Flex Slot, hot-swappable |
| Management | HPE iLO 6 |
| Security | Silicon Root of Trust, TPM support |
| Form Factor | 1U Rack |
| Operating Temperature | Standard data-center range |
