The Ubiquiti UVC-AI-MS-4-W is a white UniFi AI Multi Sensor 4 security camera combining four 8MP imaging sensors into a single 32MP surveillance platform. Each sensor provides 3840 × 2160 resolution, while independent optical coverage allows the camera to monitor multiple areas from a single installation point.
Multisensor Imaging
The camera uses four 1/2.8-inch 8MP sensors with 3.18–7.42 mm lenses and 2.33x optical zoom. Each imaging channel supports up to 3840 × 2160 resolution, providing a combined 32MP imaging system. Wide and telephoto fields of view allow coverage to be adjusted according to the monitored area.
AI Detection and Recognition
The UVC-AI-MS-4-W supports face recognition, license plate recognition, and smart detection of people, vehicles, and animals. These capabilities are designed for surveillance workflows managed through UniFi Protect.
Night Vision and Surveillance
Sixteen adaptive infrared LEDs provide up to 20 meters of infrared night vision. The camera also provides image controls including HDR, 2D noise reduction, 3D noise reduction, motion-based noise reduction, masking, exposure control, and white balance adjustment.
Network and Power
A Gigabit Ethernet RJ45 interface provides network connectivity. The camera uses PoE++ for power and supports 42.5–57V DC with maximum power consumption of 34.6W.
Storage and Expansion
The camera provides two MicroSD card slots and one M.2 2280 SATA SSD expansion slot for local storage options. A factory-reset button is also provided on the camera.
Outdoor and Vandal-Resistant Construction
The aluminum alloy and polycarbonate enclosure provides IP66 weatherproofing and IK10 impact resistance. Ceiling mounting is included, while pole, corner, arm, and pendant mounting options are available separately.
Key Features
- Four 8MP sensors providing 32MP combined resolution
- 2.33x optical zoom with 3.18–7.42 mm lenses
- 20 m adaptive infrared night vision
- Face recognition, license plate recognition, and smart detection
- IP66 weatherproofing and IK10 impact resistance
Applications
The UVC-AI-MS-4-W is suited to commercial buildings, campuses, parking areas, building perimeters, entrances, retail environments, and other locations requiring multi-directional surveillance from a centralized camera position.
DC Supplies Product Note
The four-sensor architecture allows multiple surveillance views to be consolidated into one camera installation, reducing the need to deploy separate camera bodies for each monitored direction.
Specifications
| Brand | Ubiquiti |
| Part Number / MPN | UVC-AI-MS-4-W |
| Product Type | 32MP Multisensor PoE++ Security Camera |
| Series | UniFi AI Multi Sensor 4 |
| Color | White |
| Total Resolution | 32MP |
| Number of Sensors | 4 |
| Resolution per Sensor | 8MP, 3840 × 2160 |
| Image Sensor | 1/2.8-inch 8MP CMOS |
| Lens | 3.18–7.42 mm, f/1.8–f/2.8 |
| Optical Zoom | 2.33x |
| Wide Field of View | 108.8° H / 57.6° V / 130.8° D |
| Telephoto Field of View | 42.8° H / 24.1° V / 49.1° D |
| Maximum Frame Rate | 24 FPS |
| IR Night Vision | 20 m |
| IR LEDs | 16 with adaptive control |
| Networking Interface | 1 × Gigabit Ethernet RJ45 |
| Power Method | PoE++ |
| Supported Voltage Range | 42.5–57V DC |
| Maximum Power Consumption | 34.6W |
| Smart Detection | People, vehicles, animals |
| Recognition | Face recognition, license plate recognition |
| Storage | 2 × MicroSD, 1 × M.2 2280 SATA SSD |
| Weatherproofing | IP66 |
| Tamper Resistance | IK10 |
| Mounting | Ceiling mount included; pole, corner, arm, pendant optional |
| Operating Temperature | -20 to 50°C |
| Operating Humidity | 0–90% noncondensing |
| Enclosure Material | Aluminum alloy, polycarbonate |
| Mount Material | Powder-coated aluminum alloy |
| Processor | Dual-core Arm Cortex-A76 based chip |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
FAQs
How many cameras are integrated into the UVC-AI-MS-4-W?
The unit integrates four independent 8MP imaging sensors, providing 32MP combined resolution.
Does the camera support optical zoom?
Yes. Each imaging system uses a 3.18–7.42 mm lens with 2.33x optical zoom.
What AI features does the camera support?
It supports face recognition, license plate recognition, and smart detection of people, vehicles, and animals.
How far does the infrared night vision reach?
The built-in adaptive IR system provides night vision up to 20 meters.
How is the camera powered?
The camera uses PoE++ and supports a 42.5–57V DC input range, with maximum power consumption of 34.6W.
Can the camera be installed outdoors?
Yes. The UVC-AI-MS-4-W has IP66 weatherproofing and IK10 impact resistance and supports ceiling mounting as standard, with additional mounting options available separately.
