Overview
The Ubiquiti UVC-AI-PTZ-B is an industrial-grade UniFi AI PTZ camera designed for long-range surveillance and active subject tracking. It combines 4K imaging, 22x optical zoom, 360° endless pan, 120° tilt, adaptive infrared illumination, and advanced AI capabilities in a weather-resistant enclosure.
Imaging and Optical Zoom
The camera uses a 1/1.8-inch 8MP sensor and captures 3840 × 2160 video at up to 30 FPS. Its 6.36–138.5 mm lens provides 22x optical zoom, with a wide field of view of 59.8° horizontal, 44.4° vertical, and 70° diagonal, narrowing to 3° horizontal, 2.24° vertical, and 3.76° diagonal at the telephoto end.
PTZ Operation
The motorized PTZ mechanism provides 360° endless pan and 120° tilt, allowing operators to monitor broad areas and reposition the camera toward specific subjects. The camera supports low-light operation through built-in infrared illumination and an IR-cut filter.
AI and Night Vision
The UVC-AI-PTZ-B supports face recognition, license plate recognition, and smart detections for people, vehicles, and animals. Its adaptive IR LED system provides night vision up to 100 m (328 ft), extending visibility for long-range outdoor surveillance.
Network and Power
The camera provides a Gigabit Ethernet RJ45 interface and uses PoE++ for power. It supports 42.5–57V DC input and has a maximum power consumption of 51W. A microSD card slot provides local storage expansion.
Environmental Protection and Mounting
The camera has an IP66 weatherproof enclosure and is rated for operation from -40 to 50°C. The enclosure combines aluminum alloy and polycarbonate, while the mounting hardware uses powder-coated aluminum alloy. Wall, pole, and desk-stand mounting options are supported.
Key Features
- 4K 3840 × 2160 video with an 8MP sensor
- 22x optical zoom with 6.36–138.5 mm lens
- 360° endless pan and 120° tilt
- 100 m adaptive IR night vision
- AI detection with face and license plate recognition
Applications
The UVC-AI-PTZ-B is designed for large-area surveillance where operators need wide-area coverage combined with optical zoom and active PTZ control. Suitable deployments include campuses, industrial facilities, commercial properties, parking areas, transportation sites, and outdoor perimeters.
DC Supplies Product Note
The camera can consume up to 51W, so the upstream PoE++ infrastructure should provide sufficient power at the camera's maximum operating load. The 22x optical zoom and 100 m IR capability are relevant for deployments requiring observation of distant surveillance targets.
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | UVC-AI-PTZ-B |
| Product Type | PTZ Security Camera |
| Product Line | UniFi AI PTZ Industrial |
| Color | Black |
| Resolution | 8MP, 3840 × 2160 4K |
| Maximum Frame Rate | 30 FPS |
| Sensor | 1/1.8-inch 8MP |
| Lens | 6.36–138.5 mm, f/1.5–f/3.4 |
| Optical Zoom | 22x |
| Wide FOV | 59.8° H / 44.4° V / 70° D |
| Tele FOV | 3° H / 2.24° V / 3.76° D |
| Pan Range | 360° endless |
| Tilt Range | 120° |
| IR Night Vision | 100 m (328 ft) |
| Smart Detections | People, Vehicles, Animals |
| AI Recognition | Face Recognition, License Plate Recognition |
| Network Interface | 1 × Gigabit Ethernet RJ45 |
| Power Method | PoE++ |
| Supported Voltage | 42.5–57V DC |
| Maximum Power Consumption | 51W |
| Storage | MicroSD card slot |
| Weather Protection | IP66 |
| Mounting | Wall, pole, desk stand |
| Enclosure Material | Aluminum alloy, polycarbonate |
| Mount Material | Powder-coated aluminum alloy |
| Operating Temperature | -40 to 50°C (-40 to 122°F) |
| Operating Humidity | 0–90% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
FAQs
What resolution does the UVC-AI-PTZ-B support?
The camera supports 8MP 4K video at 3840 × 2160 resolution and up to 30 FPS.
How much optical zoom does the camera provide?
The UVC-AI-PTZ-B provides 22x optical zoom using a 6.36–138.5 mm lens.
How far does the infrared night vision reach?
The adaptive IR LED system provides night vision up to 100 m (328 ft).
What is the PTZ movement range?
The camera provides 360° endless pan and 120° tilt.
What power supply does the camera require?
The camera uses PoE++, supports 42.5–57V DC, and has a maximum power consumption of 51W.
